IC697ACC701 Lithium Battery - GE Fanuc

GE Fanuc IC697ACC701 Lithium Battery – High-Reliability Backup Power

Key Functions
- Maintains accurate calendar and clock operations
- Provides stable power to the BIOS and internal CPU components
- Retains user memory data during shutdown periods

Technical Highlights
• Brand: GE Fanuc
• Series: Series 90-70
• Model: IC697ACC701
• Battery Type: Lithium
• Form: Accessory
• Compatibility: Designed for IC697CPU731 and other Series 90-70 CPUs
• Installation Location: Inside CPU compartment
• Low Battery Indication: "Module OK" LED turns off
• VME Support: Yes (C1 Standard)

Performance Data
• Shelf Life: 1 year at 20°C ambient
• Memory Retention: Up to 6 months nominal without external power
• Calendar Maintenance Duration: Up to 10 years under optimal conditions
• Nominal Voltage: 3V per cell (6V total for dual configuration)
• Typical Standby Current: 1.5 µA

Installation & Handling
- Each package contains 2 lithium battery units for one CPU
- New battery must be inserted before removing the old one
- Designed to only operate when power is off, preserving energy
- Always monitor the OK LED as a battery health indicator

Model Breakdown
• IC697: Indicates Series 90-70 product classification
• ACC701: Designates accessory battery type
