IC697CPM924 Floating Point CPU - GE Fanuc

GE Fanuc IC697CPM924 Series 90-70 CPU Module – High-Performance 32-bit Control

Key Technical Highlights:

Processor Speed: 64 MHz 32-bit microprocessor

RAM Capacity: 1 MB onboard user memory

Floating Point Operation: Supported for enhanced calculation accuracy

Battery Backup Retention: Retains memory for 6 months without power

Battery Shelf Life: 1 year at 20°C (68°F)

Temperature Range: Operates from 0°C to 60°C (32°F to 140°F)

Serial Communication: 1 integrated serial port (RS-232)

Clock Accuracy: Time-of-day clock accurate to 3.5 seconds/day; Elapsed time clock within 0.1%

Expanded Functional Features:

Bus Interface: Supports high-speed communication via parallel port

Remote Programming: RUN/STOP switch and remote control via programming interface

Optional Networking: Expandable with Ethernet modules for supervisory systems

Installation Note: Power must be disconnected before module installation

Data Retention: RAM backup using a replaceable lithium battery

Additional Technical Parameters:

Instruction Processing Speed: Executes over 0.2 million Boolean instructions per second

Power Requirements: Typically consumes 5V DC at 1.2A from backplane

Program Storage: RAM allows storage of programs up to 800 KB

Cooling Requirement: Requires 100 LFM air flow minimum at max ambient temperature

Weight: Approximately 450 grams (15.9 oz)

Model Breakdown:

IC697: Indicates GE Fanuc Series 90-70 hardware

CPM: Refers to Central Processing Module type

924: Specific model identifier indicating 64 MHz CPU with 1 MB RAM
