IC754VBI06STD GE Fanuc QuickPanel Plus HMI 6 Inch

IC754VBI06STD GE Fanuc QuickPanel Plus 6-Inch Color HMI

The IC754VBI06STD is an advanced operator interface microcomputer from GE Fanuc's QuickPanel Plus product line. This all-in-one unit combines a high-resolution color touchscreen with a powerful ARM microprocessor. It is designed for enhanced communications and efficient data collection within industrial automation networks.

Core Specifications and Identification

• Manufacturer and Model: This is a GE Fanuc (Emerson) product from the QuickPanel Plus series.
• Part Number: The specific catalog number is IC754VBI06STD.
• Product Type: Functions as an all-around microcomputer operator interface.
• Key Feature: Features an advanced ARM microprocessor for improved performance.

Display and Interface

• Display Size: 6 inch diagonal screen.
• Display Color: High-resolution color graphics display.
• Input Type: Touchscreen for operator input.

Processing and Memory

• Processor: Advanced ARM microprocessor (specific model typically ARM-based).
• Memory Configuration:
  • Flash Memory: 256 MB non-volatile flash (functions as the primary storage/hard drive).
  • SRAM: 512 KB battery-backed safety backup memory for data retention during power loss.
  • Additional memory noted as 32 MB (likely DRAM for runtime).
• Memory Advantage: Divided memory architecture helps minimize the chance of operation freezes.

Communication and Connectivity

• Communication Ports: Supports RS-232 and RS-485 serial communication.
• Connectivity: Communication portals designed to easily connect with most industrial equipment.
• Communication Cable: Compatible with HMI-CAB-C110 cable.

Power and Environmental Specifications

• Power Supply: 12 to 30 VDC input.
• Environmental Rating: Requires Pollution Degree 2 environment.
• Environmental Sensitivity: Must be protected from flames, industrial residue, excessive light, dust, corrosion, moisture, and gases.
• Installation Note: Requires good ventilation and is not suitable for sites with higher pollution degrees.

Physical and Shipping Details

• Unit Weight: Approximately 2.01 kg (4.44 lbs).
• Shipping Weight: Approximately 5 lbs including packaging.
• Shipping Dimensions: Approximately 14 x 12 x 10 inches.

Packaging and Shipping

• Package Contents: Typically includes the HMI microcomputer unit and related documentation.
• Shipping Methods: Available for international delivery via FedEx, UPS, and DHL services.

Frequently Asked Questions FAQ

• What is the QuickPanel Plus series? The QuickPanel Plus line represents an enhanced generation of GE Fanuc HMIs with more powerful processors (like ARM), increased memory, and improved performance compared to earlier QuickPanel View models.
• What is the benefit of 256MB flash memory? The large non-volatile flash memory acts as a robust "hard drive," allowing storage of more complex applications, extensive historical data logs, and larger graphic libraries without the risk of data loss during power cycles.
• What does Pollution Degree 2 mean? It indicates the unit is designed for environments where only non-conductive pollution occurs. Temporary conductivity caused by condensation is expected. It is not for outdoor or heavily contaminated industrial areas.
• What type of applications is this HMI suited for? It is designed for demanding industrial systems requiring reliable performance, faster connectivity, and enhanced data collection capabilities in controlled industrial environments.

The IC754VBI06STD offers a performance upgrade within the compact 6-inch HMI form factor, featuring a modern ARM processor and substantial memory. Its design focuses on reliability and efficient operation for sophisticated automation tasks. This GE Fanuc QuickPanel Plus unit is a capable interface for modernizing control panels and enhancing operator interaction.
