About the Product

New & Original Lenze EMB9341-C Regenerative Power Supply

This high-performance regenerative power supply delivers efficient energy recovery for industrial drive systems. The Lenze EMB9341-C from the 9300 series offers advanced power management and regenerative capabilities.

Product Identification

  • Manufacturer: Lenze
  • Product Type: Regenerative Power Supply
  • Product Line: Series 9300
  • Part Number: EMB9341-C

Mains Input Specifications

  • Mains Voltage: 320 V to 528 V
  • Mains Frequency: 48 Hz to 62 Hz
  • Rated Mains Current: 12 A
  • Maximum Mains Current: 18 A
  • Apparent Power: 8.3 kVA

Power Output Specifications

  • Rated DC Bus Power: 7.2 kW
  • Maximum DC Bus Power: 10.8 kW
  • Rated DC Bus Current: 13 A
  • Maximum DC Bus Current: 19.5 A
  • Power Loss: 100 W

Motor Performance Specifications

  • Shaft Power (Motor Mode): 6.0 kW
  • Shaft Power (Generator Mode): 8.5 kW
  • Efficiency: >95% typical
  • Regeneration Capability: Full four-quadrant operation

Thermal Management

  • Operating Temperature: 0°C to 40°C standard
  • Derating: 2% per K above 40°C
  • Storage Temperature: -25°C to +70°C
  • Cooling Method: Convection cooling
  • Humidity: 5% to 95% non-condensing

Electrical Protection Features

  • Overvoltage protection
  • Undervoltage protection
  • Overcurrent protection
  • Short-circuit protection
  • Thermal overload protection

Communication & Control

  • Interface: Standard industrial communication
  • Protocols: Supported by Lenze systems
  • Control Signals: Enable, status, fault
  • Monitoring: DC bus voltage, current, temperature

Physical Specifications

  • Dimensions: Standard 9300 series housing
  • Weight: Approximately 5.5 kg
  • Mounting: Panel or DIN rail mounting
  • Protection Rating: IP20 standard

Application Areas

  • Industrial drive systems
  • Energy recovery applications
  • Servo drive power supplies
  • Motor test stands
  • Regenerative braking systems

Certifications & Standards

  • CE marked
  • UL recognized
  • RoHS compliant
  • Industrial EMC standards
  • Safety standards compliance

Package Contents

  • Regenerative Power Supply unit
  • Installation manual
  • Mounting accessories
  • Technical documentation

Warranty & Support

  • 12-month manufacturer warranty
  • Technical support available
  • Installation guidance
  • Quality assurance
