MODBUS RTU Master Slave ABB 3BSE018103R1 CI853K01

ABB 3BSE018103R1 CI853K01 COMLI MODBUS Communication Interface

The ABB 3BSE018103R1 CI853K01 provides versatile dual-protocol communication for industrial control systems. This flexible interface supports both COMLI and MODBUS RTU protocols with master/slave capability.

Product Identification & Specifications

• Article Number: 3BSE018103R1
• ABB Designation: CI853K01
• Communication Protocols: COMLI and MODBUS RTU
• Operation Mode: Master/Slave configurable
• Channel Capacity: 2 independent channels

Communication Performance

• Transmission Speed: 75 to 19,200 bps
• Connector Type: RJ-45 female 8-pin
• Hot Swap Capability: Yes, supported
• CEX Bus Capacity: 12 units maximum
• HI Controller Compatibility: Yes, supported

Electrical Specifications

• Power Supply: 24 V DC operation
• Current Consumption: 100 mA typical
• Power Calculation: 2.4 W at 24V DC
• Redundancy Support: Line and module redundancy not supported
• Protection Class: IP20 rated

Physical Specifications

• Module Width: 59 mm (2.3 inches)
• Module Height: 185 mm (7.3 inches)
• Module Depth: 127.5 mm (5.0 inches)
• Total Weight: 700 g (1.5 pounds)
• Mounting Type: Standard industrial base

Environmental Specifications

• Operating Temperature: +5 to +55 °C
• Storage Temperature: -40 to +70 °C
• Corrosion Protection: G3 compliant to ISA 71.04
• Marine Certifications: ABS, BV, DNV-GL, LR
• Environmental Compliance: RoHS and WEEE compliant

Protocol Features

• Dual protocol support capability
• Configurable master/slave operation
• Flexible baud rate selection
• Industrial communication reliability
• Standard MODBUS RTU implementation

Installation Guidelines

• Install in compatible ABB control system
• Connect using RJ-45 communication cables
• Configure baud rate and protocol settings
• Set master/slave operation mode
• Verify hot swap functionality

Package Contents

• ABB 3BSE018103R1 CI853K01 module
• Installation and configuration guide
• Technical specification documents
• Compliance certificates

Shipping & Delivery

• Fast FedEx, UPS, and DHL shipping
• Professional protective packaging
• Real-time tracking updates
• International delivery available

Frequently Asked Questions

• What protocols are supported? COMLI and MODBUS RTU
• How many channels available? 2 communication channels
• What is the speed range? 75 to 19,200 bps
• Is hot swap supported? Yes, hot swap capable
• What is the module weight? 700 grams (1.5 pounds)
