MTL - MTL5040 Transmitter Power Supply

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (16 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

MTL5040 Dual-Channel 4-20mA Isolator & Transmitter Power Supply

Core Function: Powers hazardous-area transmitters (Channel 1) and replicates signals to safe-area (Channel 2) with full electrical isolation.

Technical Specifications

Channel 1 (Transmitter Power):

  • • Output: 16.5V @20mA to transmitter
  • • Input Range: 0-24mA (4-20mA nominal)
  • • Load Resistance: ≤550Ω

Channel 2 (Signal Repeater):

  • • Accuracy: ±20μA (typ. ±5μA)
  • • Response Time: 250μs to 90% value
  • • Temp Drift: <1μA/°C

Terminal Functions

Terminal Function Channel
1, 2 Transmitter Input (-, +) 1
4, 5 Driver Output (-, +) 2
11, 12 Transmitter Output (-, +) 1
13, 14 Power Supply (-, +) -

Key Features

• Dual isolation: 250V between all circuits

• Low noise: <40μA p-p ripple

• Wide supply range: 20-35V DC

• LED power indicator

Certifications

• Zone 0, IIC, T4-T6

• Division 1, Group A

• Um = 250V rms/dc
