MTL3046B Repeater Power Supply | MTL

Product Introduction

The MTL3046B barrier safely interfaces smart transmitters in hazardous areas with control systems. This advanced unit supports both 4-20mA analog signals and digital communications simultaneously. It replaces the MTL3046 while offering enhanced compatibility with most modern smart transmitters.

Engineers can calibrate and monitor connected transmitters remotely via host systems or handheld communicators. The device maintains at least 15V at 20mA to power field transmitters while providing accurate current replication. Its wide bandwidth supports various digital protocols for comprehensive device management.

Technical Specifications

• Channels: Single fully floating channel
• Hazardous Area Certification: Zone 0, IIC, T4-6 / Div 1, Group A
• Voltage Output: 15V minimum at 20mA (28V max open-circuit)
• Signal Range: 4-20mA with digital superposition
• Bandwidth: 10Hz-8kHz (safe→hazardous) / DC-10kHz (hazardous→safe)
• Load Resistance: 20-750Ω (250Ω±10% optimal for digital)
• Accuracy: Better than 20μA at 20°C
• Response Time: 40μs to 10% of final value
• Power Consumption: 85mA typical at 24V
• Safety Ratings: FM certified with detailed entity parameters

The MTL3046B works seamlessly with both smart and traditional 4-20mA transmitters. Its robust design ensures reliable signal transmission between hazardous and safe areas. The unit particularly excels in upgrade scenarios where analog systems will transition to smart technology.
