MTL4573 | Temperature Signal Converter MTL 4500

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

MTL4573 Temperature Signal Converter

Supported Inputs and Minimum Span
Thermocouples (THC): J, K, T, E, R, S, B, N (to BS EN 60584-1:1996) — 3mV min. span
GOST XK: GOST P8.585-2001 — -75mV to +75mV
RTDs: Pt100, Pt500, Pt1000 (BS EN 60751:2008); Cu-50, Cu-53 (GOST 6651-94); Ni100, Ni500, Ni1000 (DIN43760:1985) — min. span 10Ω, 50Ω, or 100Ω
Linear Resistance: 0 to 400Ω with 10Ω minimum span

RTD Excitation and Cold Junction
Excitation Current: 200μA nominal
CJC (Cold Junction Compensation): selectable ON or OFF
CJC Error: ≤ 1.0°C

Electrical Rejection Performance
Common Mode: 120dB at 240V, 50/60Hz
Series Mode: 40dB at 50/60Hz

Calibration Accuracy (at 20°C)
Thermocouple/mV: ±15μV or ±0.05% of input
RTD (e.g., Pt100): ±80mΩ
Output: ±11μA

Temperature Drift (Typical)
THC/mV: ±0.003% of input per °C
RTD (Pt100): ±7mΩ/°C
Output: ±0.6μA/°C
