NAIO-02 ABB Analog I/O Extension Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (99 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications

Dimensions & Weight

Dimensions 2.0 x 3.0 x 5.0 inches (5.1 x 7.6 x 12.7 cm)
Weight 6.1 oz (0.2 kg)

Power Requirements

Module Power 24V DC ±10%
Current Consumption 160 mA

Signal Characteristics

Current Signal (Single-ended)
  • Range: 0(4) to 20 mA
  • Load Resistance (Rload): 700 Ω
  • Isolation: Isolated from power and ground
Current Signal (Differential)
  • Range: ±0(4) to 20 mA
  • Input Resistance (Rin): 100 Ω
  • Isolation: Isolated from power and ground
Voltage Signal (Differential)
  • Range: ±0(2) to 10V or ±0 to 2V
  • Input Resistance (Rin): 200 kΩ
  • Isolation: Isolated from power and ground

Communication Interfaces

Fiber Optic Ports 2 ports for high-integrity data transmission

Configuration

Node Address Configurable via 7 DIP switches
Address Range 0 to 127

Analog Input Filtering

Filter Time (Hardware) Approx. 20 ms for stable signal acquisition
