New Power Supply | Bently Nevada 3500/15-04-04-02

Bently Nevada 3500/15 Power Supply Module

Part Number: 3500/15-04-04-02

Model: 3500/15 Power Supply

Manufacturer: Bently Nevada

Ordering Information

Model: 3500/15 Power Supply

Power Supply Type (Top Slot): 04 - Low Voltage DC (20 to 30 Vdc)

Power Supply Type (Bottom Slot): 04 - Low Voltage AC (20 to 30 Vdc)

Agency Approval: 02 - ATEX / IECEx / CSA (Class 1, Zone 2)

Power Supply Module Specifications

Dimensions: 120.7 mm x 50.8 mm x 251.5 mm (4.75 in x 2.0 in x 9.9 in)

Weight: 1.39 kg (3.06 lb)

Full Rack Current Draw

High Voltage AC: 2.3 A rms (maximum)

Low Voltage AC: 4.5 A rms (maximum)

Universal Voltage AC: 2.8 A rms (maximum)

High Voltage DC: 2.5 A (maximum)

Low Voltage DC: 10.0 A (maximum)

Additional Features

Input Voltage Range: 20 to 30 Vdc for both top and bottom slots, ensuring compatibility with low voltage systems.

Efficiency: High efficiency rating of 92%, reducing energy consumption and operational costs.

Operating Temperature Range: -30 °C to +65 °C (-22 °F to +150 °F), suitable for harsh environments.

Storage Temperature Range: -40 °C to +85 °C (-40 °F to +185 °F), ensuring durability during non-operational periods.
