Passive Speed Sensor AI-Tek | 70085-1010-414

Passive Speed Sensor 70085-1010-414 by AI-Tek Instruments

Product Overview

This is a new original passive speed sensor. It is used to measure rotational speed. It comes in its original factory packaging. It has a 12-month warranty. We ship fast with Fedex, UPS, and DHL.

Key Technical Parameters

Range: 0 to 10000 RPM

Gap Range: 0.020 to 0.060 in

Output Signal: AC Voltage, Sine Wave

Voltage at 1000 RPM: 2.5 VAC (min)

DC Resistance: 200 ohms

Operating Temperature: -65 to +100°C

Thread Size: 0.625-18 UNF

Where To Use This Sensor

It is perfect for heavy industrial machines. Use it on gearboxes, large engines, and motor shafts. It helps monitor speed to prevent damage. It solves the problem of not knowing if a machine is running too fast or too slow. This prevents costly downtime and repairs.

What Is In The Box

You will receive one speed sensor. The package includes the sensor only. No certificates or manuals are included.

How To Install

Mount the sensor near a gear or notched wheel. The tip must face the gear teeth. Keep a gap of about 0.040 inches. Connect the two wires to your monitoring system. It is very easy to install.

Works With These Systems

This sensor works with most tachometers and PLC systems. It is a direct replacement for many old sensors in turbines, pumps, and conveyors. Check your old part number to confirm.
