About the Product

Allen-Bradley 1785-L46C15 PLC-5/46C ControlNet Processor

Core Specifications
Processor Type PLC-5/46C with Protected Memory
Memory Capacity 48K words (32K max per data table)
Weight 1.36kg
Analog I/O 2048 Forcible + 48000 Nonforcible
Backplane Current 3.3A @ 5V DC
Network Performance
ControlNet Port 5Mbps (99 nodes with repeaters)
DH+/RIO Ports 2 ports (57.6K-230.4K bit/s)
Scan Times 0.5ms (ControlNet), 3-10ms (Remote I/O)
Hot Backup Supported (1785-CHBM cartridge)
System Architecture
Max I/O Chassis 125 total (60 remote max)
I/O Racks 15 rack capacity
Compatible I/O 1771, 1794, 1746, 1791 (8/16/32-pt & intelligent)
Addressing Modes ½-slot, single-slot, double-slot
Environmental Ratings
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5-95% non-condensing
Shock/Vibration 30G shock, 1G vibration (10-500Hz)

Key Features

  • High-density ControlNet processor with protected memory
  • Massive I/O capacity (2048 forcible + 48000 nonforcible points)
  • Redundant ControlNet hot backup capability
  • Industrial-grade durability with wide temperature operation
  • Multiple addressing modes for flexible I/O configuration

Certifications

UL, CE, CSA, C-TICK certified

Physical Specifications

• Weight: 1.42kg (3lbs)

• Enclosure: Open-style

• Chassis Keying: Pins 40/42 and 54/56

Order Information

• Part Number: 1785-L46C15

• In stock - ready for immediate shipment

• Global shipping options available

• 12-month manufacturer warranty

  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
