Proximity Transducer Bently Nevada 330881-00-04-150-06-02

Product Overview

Manufacturer: Bently Nevada

Product No.: 330881-00-04-150-06-02

Product Type: PROXPAC XL Proximity Transducer

Made in: U.S.A

The 330881-00-04-150-06-02 proximitor sensor delivers reliable vibration monitoring for industrial rotating equipment systems.

Key Configuration

• This configuration includes a proximitor sensor without probe, allowing flexible system integration.
• 40 mm standoff adapter ensures stable mounting in compact and complex installation environments.
• 150 mm penetration configuration supports precise positioning and measurement stability.
• Includes NPT fitting with stainless steel reducer and plugs for secure installation and sealing.
• 3/4-14 NPT mounting thread ensures compatibility with standard industrial mounting systems.

Technical Specifications

• Brand: Bently Nevada
• Model: 330881-00-04-150-06-02
• Linear Range: 2 mm (0.25 mm to 2.3 mm)
• Frequency Response: 0 to 10 kHz
• Sensitivity: 7.87 V/mm ±5%
• Resolution: High precision within ±0.025 mm deviation
• Recommended Gap: 1.27 mm
• Output Resistance: 50 Ω
• Supply Voltage: -17.5 Vdc to -26 Vdc

Mechanical and Material Details

• IP66-rated housing protects the device from dust and powerful water jets.
• PPS materials provide strong chemical resistance and long-term mechanical durability.
• Stainless steel construction improves corrosion resistance in harsh industrial environments.
• UV-resistant housing ensures stable performance in outdoor and high exposure conditions.
• ClickLoc connector design allows fast and secure electrical connections.
• Silicone vibration isolation reduces mechanical noise and improves measurement stability.

Environmental Performance

• Operating temperature ranges from -51°C to +177°C for demanding industrial applications.
• System maintains stable output under extreme environmental and temperature variations.
• Certified impact resistance ensures durability under mechanical shock conditions.
• Wide temperature classification supports hazardous and industrial installation environments.

Installation Guidelines

• Set the probe gap to 1.27 mm to achieve optimal measurement accuracy.
• Use shielded triaxial cables to reduce electromagnetic interference during operation.
• Apply recommended torque values to ensure secure and stable installation.
• Keep wiring length below 305 metres to maintain signal quality and frequency response.

Packing List

• 1 × PROXPAC XL proximitor sensor unit
• 1 × Installation fittings set
• 1 × Accessory kit

FAQ

• Can this model operate without a probe?
  Yes, this configuration allows flexible integration with compatible external probes.
• What industries commonly use this sensor?
  Industries use this sensor for turbines, compressors, pumps, and rotating machinery monitoring.
• How do I ensure signal stability?
  Use proper shielding cables and maintain correct installation distance for stable performance.
• Is this model suitable for harsh environments?
  Yes, the IP66 housing and robust materials ensure reliable performance in demanding conditions.
