Relay I/O Base Module - Schneider Electric TSXDMZ28DR

Schneider Electric TSXDMZ28DR Discrete Relay I/O Base

The TSXDMZ28DR from Schneider Electric is a versatile discrete relay I/O base for TSX Micro PLC systems. This module provides reliable relay output switching and digital input capability for industrial control applications.

Technical Specifications

• Brand & Model: Schneider Electric TSXDMZ28DR
• Product Type: Discrete Relay I/O Base Module
• Discrete Inputs: 16 channels via screw terminal blocks
• Input Voltage: 24 V DC, negative logic compatible
• Input Current: 9 mA per channel typical
• Output Voltage Range: Wide range 10-34 V DC and 19-264 V AC
• Contact Type: Normally Open (NO) relay contacts

Input Electrical Characteristics

• Input Logic Thresholds: State 0: ≤1.5 mA, State 1: ≥2.5 mA
• Input Voltage Limit: ≤8 V at logic state 1
• Input Impedance: 4 Ohm typical
• Response Time: Fast 0.1 to 7.5 ms for state transitions
• Sensor Compatibility: Works with 2-wire and 3-wire proximity sensors
• IEC 1131-2 Type 1 input specifications

Relay Output Specifications

• Contact Configuration: Normally Open (NO) form A contacts
• Isolation Voltage: High 1500 V for 1 second protection
• Insulation Resistance: ≥10 MOhm for safety and reliability
• Load Type: Designed for resistive loads; consult datasheet for inductive
• Conventional Thermal Current [Ith]: 3 A in free air

Power & Switching Capacity

• Power Dissipation: 4.5 W typical during operation
• Current Consumption: 160 mA (positive) and 131 mA (negative)
• Output Switching Capacity (Resistive):
  • 50 VA at 24 V AC
  • 110 VA at 48 V AC
  • 220 VA at 110/220 V AC
  • 40 W at 24 V DC
• Output Switching Capacity (Inductive):
  • 24 VA at 24/48 V AC
  • 110/220 VA at 110/220 V AC
  • 24 W at 24 V DC

Performance & Response Times

• Input response: 0.1-7.5 ms from state 0 to 1 and vice versa
• Output response: < 10 ms switching time
• Designed for fast industrial control cycle requirements
• Reliable operation in repetitive switching applications

Physical Design

• Connection Type: 16 screw terminal blocks for secure field wiring
• Net Weight: 0.5 kg (1.1 lb) lightweight construction
• Standard TSX Micro module format for rack mounting
• Compact design saves valuable panel space

Packaging & Shipping

• The TSXDMZ28DR I/O base ships as one complete module.
• Includes all necessary hardware for installation.
• Protected in industrial-grade packaging.
• Fast worldwide delivery via FedEx, UPS, and DHL couriers.

Frequently Asked Questions (FAQ)

• What is a discrete relay I/O base? It is a combined module that provides both digital inputs and relay outputs for a PLC system.
• What types of loads can the relays switch? They are rated for resistive loads (lamps, heaters) and specific inductive loads (contactors, solenoids) as per the power ratings.
• What does "negative logic" input mean? The input is active (State 1) when the terminal is connected to 0V/negative, common with PNP sensors.
• How many devices can I connect? It has 16 discrete input points and corresponding relay outputs.
• What is the isolation rating? It provides 1500 V isolation between the relay contacts and the PLC logic for safety.
• Is it compatible with 3-wire sensors? Yes, it is compatible with both 2-wire and 3-wire PNP-type proximity sensors.
• How is it powered? It receives power from the TSX PLC rack's backplane (160mA positive, 131mA negative).
