Relay Output Module | 1769-OW16 16-Channel

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1769-OW16 16-Channel Relay Output Module

Key Features

  • 16 normally open relay outputs (8 points per group)
  • Wide voltage range: 5-265V AC / 5-125V DC
  • 2.5A maximum current per point
  • 20A maximum current per module
  • 10ms switching response time

Technical Specifications

Output Type: Form A (NO) relay contacts
Contact Rating: 2.5A @ 125V DC / 7.5A @ 240V AC
Isolation: 1836V AC for 1 second (point-to-bus)
Power Consumption: 4.75W maximum
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Dimensions: 118 x 52.5 x 87mm (4.65 x 2.07 x 3.43in)
Weight: 0.41kg

Compatible Systems

  • CompactLogix controllers
  • MicroLogix 1500 systems
  • 1769-PA2/PB2/PA4/PB4 power supplies
  • Studio 5000 programming software

Wiring Information

  • 22-14 AWG solid copper wire
  • 22-16 AWG stranded copper wire
  • 90°C (194°F) rated wire
  • Removable terminal block

Industrial Applications

  • Motor starter control
  • Solenoid valve operation
  • Lighting control systems
  • Conveyor system controls
  • HVAC equipment switching

Package Contents

  • 1769-OW16 relay output module
  • Removable terminal block
  • Mounting hardware
  • Installation documentation
