Schneider Electric 140CPS11420C Power Supply Module

Schneider Electric Modicon Quantum Power Supply Module

The 140CPS11420C is a modular power supply from Schneider Electric's Modicon Quantum series. This power supply module delivers reliable DC power for industrial control systems. It offers dual input voltage capability for flexible installation options.

Core Technical Specifications

• Brand & Model: Schneider Electric 140CPS11420C (Modicon Quantum Series)
• Input Voltage: 115 Volts AC or 230 Volts AC dual input
• Output Voltage: Provides 5.1 Volts DC stable output
• Output Current: Maximum 11 Amps continuous current
• Rated Power: 130 Volt-Amps total power capacity
• Product Type: Power supply module for control systems
• Relay Contact: Normally closed relay for system control

Electrical Specifications

• Input Current (115V): 1300 Milliamps at 115 Volts AC
• Input Current (230V): 750 Milliamps at 230 Volts AC
• Inrush Current (115V): 38 Amps maximum at startup
• Inrush Current (230V): 19 Amps maximum at startup
• Relay Rating (AC): 220 Volts AC at 6 Amps capacity
• Relay Rating (DC): 30 Volts DC at 5 Amps capacity

Physical & Environmental Specifications

• Operating Temperature: 0°C to 60°C reliable operation range
• Module Dimensions: 40mm width × 250mm height × 104mm depth
• Module Weight: 1.5 Kilograms (3.3 Pounds) total weight
• Mounting Style: Modular design for Quantum rack installation
• Application: Industrial control system power supply

Installation Guidelines

• Install in Modicon Quantum series control racks or enclosures
• Select appropriate input voltage (115V or 230V) for your location
• Ensure operating environment stays within 0°C to 60°C range
• Connect relay contacts according to system control requirements
• Allow adequate clearance for heat dissipation around module

Packaging & Shipping Information

• Includes one Schneider Electric 140CPS11420C power module
• Package contains installation guide and technical documentation
• We ship via reliable carriers including FedEx, UPS, and DHL
• Package weight approximately 1.5 kg (3.3 lbs) with protection

Frequently Asked Questions

• What voltages does it accept? 115V AC or 230V AC input.
• What is the output voltage? 5.1 Volts DC for system power.
• What is the maximum current? 11 Amps continuous output.
• Does it include a relay? Yes, normally closed relay contact.
• What temperature does it work in? 0°C to 60°C range.
