Schneider Electric 140CPS22400C | Backup Power Supply Module

Core Product Overview

• The Schneider Electric 140CPS22400C is a redundant power supply module.
• This unit provides backup power for critical automation systems.
• It ensures continuous operation for Modicon Quantum platform applications.

Key Technical Specifications

• Brand & Model: Schneider Electric 140CPS22400C
• Input Voltage: 20-30V DC wide input range
• Output Voltage: Stable 5.1V DC system power
• Output Current: 8A redundant output capacity
• Redundancy: Built-in redundancy for fault tolerance
• Alarm Output: NC contact for power supply fault signaling
• UL Listed: Compliant with safety standards

Electrical & Protection Features

• Input Current: Maximum 3.8A input current
• Inrush Current: 25A @ 24V DC startup handling
• Overvoltage Protection: Internal protection circuitry
• Overload Protection: Withstands 2.3x rated voltage for 1.3ms
• Power Dissipation: 6 + (1.8 × Iout) watts formula
• Monitoring: LED indicators for status visualization

System Integration & Monitoring

• Fault Contact: 6A, 220V rated NC alarm contact
• Redundancy Design: Ensures system uptime during failures
• Installation: Standard Quantum rack mounting
• Compatibility: Designed for Quantum series backplanes
• Reliability: Engineered for critical process applications
• Certification: UL listed for safety assurance

Installation & Wiring

• Install the 140CPS22400C module in your Quantum rack
• Connect 20-30V DC input power to the designated terminals
• Wire the alarm contact to your monitoring or control system
• Ensure proper redundancy configuration with existing power supplies
• Monitor LED indicators for proper operational status

Packaging & Delivery

• One Schneider Electric 140CPS22400C redundant power supply
• Includes installation manual and wiring diagrams
• Shipping via FedEx, UPS, or DHL express delivery
• Ready for critical system power integration

Frequently Asked Questions

What is the main purpose of this power supply?

The 140CPS22400C provides redundant backup power for critical systems.

What is the output voltage and current?

It delivers 5.1V DC with 8A redundant output capacity.

How does the redundancy feature work?

It maintains power supply if one unit fails, ensuring system continuity.

Is there a fault alarm output?

Yes, a normally closed contact signals power supply faults.

What input voltage is required?

It operates from a 20-30V DC input power source.
