Schneider Electric 140DDO15310 TTL Output Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (18 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

High-Speed TTL Output Module for Precision Control

The Schneider Electric 140DDO15310 delivers 32 high-speed TTL outputs for Modicon Quantum systems. This module excels in low-voltage digital control applications requiring microsecond response times.

Key Features

  • 32 TTL outputs - Organized in 4 isolated groups (8 channels each)
  • Ultra-fast switching - 250µs response time (both ON/OFF)
  • 5V DC operation - 4-5.5V range with 440Ω internal pull-up
  • Robust protection - TVS diodes and fused outputs (75mA/point)
  • High surge tolerance - Handles 750A pulses (0.5ms duration)
  • Comprehensive diagnostics - 32 channel LEDs + fault indicators

Technical Specifications

  • Output type: Positive (sink) TTL logic
  • Current rating: 75mA/point (600mA/group, 2.4A total)
  • Isolation: 500Vrms between channel groups
  • Power consumption: 4W (2800mA @5V DC)
  • Environmental: 0-60°C operation, 95% humidity
  • Certifications: UL 508, CSA, FM Class 1 Div 2, GOST

Industrial-Grade Reliability

Designed for demanding automation environments, this module features:

  • 4kV ESD/8kV air discharge protection
  • 10V/m EMI resistance (80-2000MHz)
  • 5000m altitude operation capability
