Schneider Electric 140DDO84300C 16-Channel DC Output

Schneider Electric Modicon Quantum Discrete Output Module

The 140DDO84300C is a 16-channel discrete output module from Schneider Electric's Modicon Quantum series. This output module provides reliable control for industrial automation systems. It offers positive logic output with comprehensive protection features.

Core Technical Specifications

• Brand & Model: Schneider Electric 140DDO84300C (Modicon Quantum Series)
• Output Channels: 16 discrete output points total
• Channel Groups: 2 groups with 8 channels each
• Output Logic: Positive logic (source) configuration
• Voltage Range: 10 to 60 Volts DC operating range
• Voltage Limits: 10.2 to 72 Volts DC absolute range
• Address Requirement: 1 output word for system addressing

Electrical & Current Specifications

• Point Current: 2 Amperes maximum per individual output point
• Group Current: 6 Amperes maximum per 8-channel group
• Module Current: 12 Amperes maximum total module current
• Bus Current: 160mA requirement from backplane
• Voltage Drop: <1 Volt at 2 Amperes maximum drop
• Surge Current: 7.5 Amperes for 50 seconds capability

Performance & Timing Specifications

• Response Time: 1 millisecond maximum for state changes
• Maximum Voltage: 72 Volts DC permanent absolute maximum
• Leakage Current: <1mA at 60 Volts maximum leakage
• Power Dissipation: 1W + (1V × total load current)
• Load Inductance: Calculated based on current and frequency
• Isolation (Channel-Bus): 2500Vrms for 1 minute protection

Protection & Safety Features

• Fuse Protection: 8 Ampere fuse per output group protection
• Point Fuses: 2 Ampere fuse for each individual output point
• Isolation (Group-Group): 700Vrms for 1 minute isolation
• ESD Protection: 4kV contact, 8kV air discharge resistance
• EMC Immunity: 10V/m 80-2000MHz electromagnetic fields
• Certifications: FM Class 1 Div 2, CSA, UL 508, GOST, C-tick

Environmental & Physical Specifications

• Operating Temperature: 0°C to 60°C industrial range
• Storage Temperature: -40°C to 85°C extended range
• Module Weight: 0.45 kilograms net weight
• Relative Humidity: 95% maximum non-condensing
• Operating Altitude: Up to 5000 meters altitude capability
• Protective Coating: Conformal coating for environmental protection

Indicator & Monitoring Features

• Channel LEDs: 16 green LEDs for individual output status
• Active LED: Green LED for bus communication presence
• Fault LED: Red LED for external fault detection
• Total Indicators: 17 green LEDs and 1 red LED total
• Module Format: Standard Quantum module dimensions
• Fault Detection: External fault detection capability

Installation Guidelines

• Install in Modicon Quantum series control racks or enclosures
• Connect 10-60VDC power within specified voltage limits
• Observe current limits: 2A per point, 6A per group, 12A total module
• Monitor LED indicators for output status and fault conditions
• Ensure proper fuse protection for each output group
• Maintain operating environment within 0-60°C temperature range

Packaging & Shipping Information

• Includes one Schneider Electric 140DDO84300C output module
• Package dimensions: 31.2cm × 16.3cm × 4.5cm
• Package weight: 680 grams with protective packaging
• We ship via reliable carriers including FedEx, UPS, and DHL
• Industrial packaging ensures component protection during transit

Frequently Asked Questions

• How many output channels? 16 discrete output points.
• What voltage range? 10-60VDC operating range.
• What is the response time? 1 millisecond maximum.
• What fuse protection? 8A per group, 2A per point.
• How many status LEDs? 17 green and 1 red LED indicators.
