Schneider Electric 140NOL91110 78 kbps Transceiver

Schneider Electric Modicon Quantum Transceiver

The 140NOL91110 is a LonWorks network transceiver from Schneider Electric's Modicon Quantum series. This transceiver provides reliable communication for industrial automation systems. It supports the LonWorks interface for building automation networks.

Core Technical Specifications

• Brand & Model: Schneider Electric 140NOL91110 (Modicon Quantum Series)
• Product Type: Quantum LonWorks network transceiver
• Interface Type: LonWorks building automation interface
• Data Rate: 78 kilobits per second transmission speed
• Transmission Type: TPT/XF-78 communication protocol
• Bus Voltage: 24 Volts DC operating voltage
• Current Rating: 150 milliamps operating current

Electrical & Power Specifications

• Power Supply: 24 Volts DC required power input
• Current Consumption: 150 mA typical operating current
• Bus Compatibility: LonWorks network bus standard
• Signal Transmission: Reliable data communication capability
• Network Integration: LonWorks network connectivity
• System Interface: Quantum backplane integration

Environmental Specifications

• Operating Temperature: -20°C to 60°C wide temperature range
• Storage Temperature: -40°C to 85°C extended storage range
• Operating Humidity: Up to 80% RH non-condensing maximum
• Storage Humidity: Up to 80% RH non-condensing maximum
• Operating Altitude: 1000 meters above sea level maximum
• Storage Altitude: 1000 meters above sea level maximum

Physical & Installation Features

• Mounting Type: DIN rail mounting for easy installation
• Module Weight: 0.45 kilograms lightweight design
• Package Weight: 6.80 kilograms shipping weight
• Installation Method: Standard DIN rail mounting system
• Connection Type: LonWorks network connections
• Enclosure Design: Industrial-grade housing

Network & Communication Features

• Protocol Support: LonWorks building automation protocol
• Data Speed: 78 kbps reliable transmission rate
• Network Type: TPT/XF-78 communication standard
• System Integration: Modicon Quantum platform compatibility
• Building Automation: Designed for facility management systems
• Device Connectivity: Multiple device network support

Installation Guidelines

• Mount on standard DIN rail in control cabinet or enclosure
• Connect 24V DC power supply with proper polarity
• Wire LonWorks network cables according to specifications
• Maintain operating environment within -20°C to 60°C range
• Ensure installation area meets humidity requirements
• Verify network connectivity and communication functionality

Application & Integration

• Building Automation: Facility management and control systems
• Industrial Networks: LonWorks based automation networks
• System Integration: Modicon Quantum system connectivity
• Network Expansion: LonWorks network extension capability
• Device Communication: Multi-device network communication
• Control Systems: Building and industrial control applications

Packaging & Shipping Information

• Includes one Schneider Electric 140NOL91110 transceiver module
• Package contains installation guide and technical documentation
• We ship via reliable carriers including FedEx, UPS, and DHL
• Shipping weight: 6.80 kilograms with protective packaging
• Industrial-grade packaging ensures component protection

Frequently Asked Questions

• What network protocol does it use? LonWorks building automation protocol.
• What data transmission rate? 78 kilobits per second speed.
• What power supply is required? 24 Volts DC power input.
• How is it mounted? Standard DIN rail mounting system.
• What temperature range? -20°C to 60°C operating temperature.
