Schneider Electric 140NOM21100C DIO Head-End Adaptor

Schneider Electric 140NOM21100C DIO Head-End Adaptor

The 140NOM21100C is a versatile communication and I/O interface module from Schneider Electric's Modicon Quantum platform. This DIO (Distributed I/O) head-end adaptor enables high-speed data exchange between the Quantum PLC and remote I/O drops using Modbus protocols.

Technical Specifications

• Brand & Model: Schneider Electric 140NOM21100C
• Product Type: DIO Head-End Adaptor
• System Platform: Modicon Quantum Automation Platform
• Communication Ports: 1 x Modbus Plus (RS-485) and 1 x Modbus (RS-232)
• Transmission Speed: High-speed 1 Mbps (1 Mbit/s)
• I/O Capacity: 30 Input words / 32 Output words
• Bus Current: 780 mA requirement
• Power Dissipation: 4 W

Communication & Integration

• Acts as the primary interface for a Modbus Plus network, linking the Quantum CPU to remote I/O drops
• The RS-232 port provides a point-to-point connection for programming, diagnostics, or legacy devices
• Compatible with Quantum remote I/O adaptors 140CRA21110 and 140CRA21120
• Features internal checks for RAM address, processor, and checksum for enhanced reliability

Environmental Durability

• Operating Temperature: 0 to 60 °C (32 to 140 °F)
• Storage Temperature: -40 to 85 °C (-40 to 185 °F)
• Humidity: Up to 95% non-condensing
• Operating Altitude: Up to 5000 meters (16,404 ft)
• ESD Protection: High resistance: 4 kV (contact), 8 kV (air) per IEC 801-2
• EMC Immunity: 10 V/m (80-2000 MHz) per IEC 801-3
• Protective Coating: Conformal coating (Humiseal 1A33) for protection against moisture and contaminants

Physical Design

• Module Format: Standard Quantum module form factor
• Designed for installation in a Modicon Quantum rack or drop enclosure

Certifications & Standards

• Safety: UL 508 listed
• Hazardous Location: FM Class 1 Division 2 certified
• Regional: CSA, GOST, C-Tick approvals
• Marine: RMRS certification

Packaging & Shipping

• Unit Package (PCE): 1 module per box.
  Dimensions: 31.5 x 16.5 x 4.8 cm (12.4" x 6.5" x 1.89").
  Weight: 490 g (17.3 oz).
• Bulk Package (S02): 2 modules per box.
  Dimensions: 40 x 30 x 15 cm (15.75" x 11.81" x 5.91").
  Weight: 1.016 kg (2.24 lb).
• Worldwide shipping via FedEx, UPS, and DHL available.

Frequently Asked Questions (FAQ)

• What is a DIO Head-End Adaptor? It is the master communication module that connects a Quantum PLC rack to a network of remote I/O drops via Modbus Plus.
• What is the difference between the two ports? The RS-485 port is for the multi-drop Modbus Plus network. The RS-232 port is for a simple point-to-point connection.
• What remote I/O is it compatible with? It is designed to work with Quantum remote I/O adaptors like the 140CRA21110 and 140CRA21120.
• What does "30 I/32 O words" mean? It can map 30 words (480 bits) of input data and 32 words (512 bits) of output data between the CPU and the remote I/O network.
• What is the conformal coating for? The Humiseal coating protects the board's circuitry from humidity, dust, and corrosive atmospheres, extending its life in harsh environments.
• Can it be used in hazardous areas? Yes, its FM Class 1 Division 2 certification allows its use in certain hazardous locations.
• Is it programmable? No, it is a communication hardware module. Configuration of the network is done within the Quantum PLC programming software (Unity Pro).
