Schneider Electric 140NRP95400 Multi-mode Repeater

Schneider Electric Modicon Quantum Fiber Optic Repeater

The 140NRP95400 is a fiber optic repeater from Schneider Electric's Modicon Quantum series. This repeater extends and boosts optical signals in industrial networks. It provides reliable signal transmission with multi-mode fiber support.

Core Technical Specifications

• Brand & Model: Schneider Electric 140NRP95400 (Modicon Quantum Series)
• Product Type: Fiber optic signal repeater module
• Fiber Type: Multi-mode optical fiber compatibility
• Wavelength: 820 nanometer operating wavelength
• Port Configuration: 2 ST fiber ports + 1 coaxial port
• Bus Current: 700 milliamps required current
• Power Dissipation: 5 Watts typical power consumption

Optical & Electrical Specifications

• Receiver Sensitivity: -30 dBm minimum signal detection
• Dynamic Range: 20 dB signal range capability
• Silence Detection: -36 dBm detected silence level
• Rise/Fall Time: 20 nanosecond signal transition
• Inrush Current: 1 Ampere at 5VDC maximum
• Power Requirement: 5VDC standard power input

Port & Connection Features

• Fiber Ports: 2 ST connector optical ports
• Coaxial Port: 1 additional coaxial connection
• Connector Type: ST standard fiber connectors
• Total Ports: 3 connection ports total
• Fiber Compatibility: Multi-mode optical fiber
• Signal Regeneration: Optical signal boosting capability

Physical & Indicator Features

• Material Construction: Polycarbonate (PC) durable housing
• Module Weight: 0.65 kilograms (1.44 pounds)
• Dimensions: 40.34mm × 250mm × 103.85mm
• LED Indicators: Status indication lights
• Enclosure Design: Industrial-grade protective housing
• Mounting Type: Standard Quantum module mounting

Performance Specifications

• Signal Processing: Optical signal amplification
• Network Extension: Fiber network distance extension
• Signal Quality: Maintained signal integrity
• Data Integrity: Reliable data transmission
• System Integration: Quantum platform compatibility
• Network Reliability: Enhanced signal stability

Installation Guidelines

• Install in Modicon Quantum series control racks or enclosures
• Connect multi-mode fiber optic cables to ST ports
• Use proper fiber optic cable cleaning and handling procedures
• Connect coaxial cable to additional port if required
• Monitor LED indicators for operational status
• Ensure proper power supply connection and grounding

Network Integration Features

• Fiber Network Support: Multi-mode fiber optic networks
• Signal Boosting: Optical signal amplification function
• Distance Extension: Extended network range capability
• Network Reliability: Improved signal transmission quality
• System Compatibility: Modicon Quantum platform integration
• Industrial Applications: Factory and process networks

Packaging & Shipping Information

• Includes one Schneider Electric 140NRP95400 repeater module
• Package contains installation guide and technical documentation
• We ship via reliable carriers including FedEx, UPS, and DHL
• Shipping weight: 0.65 kg with protective packaging
• Industrial-grade packaging ensures component protection

Frequently Asked Questions

• What fiber type does it support? Multi-mode optical fiber.
• How many fiber ports? 2 ST connector fiber ports.
• What wavelength does it use? 820 nanometer operating wavelength.
• What power does it consume? 5 Watts typical power dissipation.
• What are the dimensions? 40.34mm × 250mm × 103.85mm.
