Schneider Electric 140NRP95401 Single-mode Repeater

Schneider Electric Modicon Quantum Repeater Module

The 140NRP95401 is a fiber optic repeater module from Schneider Electric's Modicon Quantum series. This repeater enhances signal integrity in communication networks. It supports both fiber optic and coaxial connections for flexible installation.

Core Technical Specifications

• Brand & Model: Schneider Electric 140NRP95401 (Modicon Quantum Series)
• Product Type: Fiber optic and coaxial repeater module
• Fiber Type: Single-mode optical fiber support
• Connection Types: Fiber optic and coaxial connectivity
• Certification: CE marked for regulatory compliance
• Repeater Function: Signal regeneration and amplification
• Network Support: Communication network enhancement

Environmental Specifications

• Operating Temperature: 0°C to 40°C reliable performance range
• Storage Temperature: 0°C to 50°C safe storage conditions
• Operating Humidity: Up to 80% RH non-condensing maximum
• Storage Humidity: Up to 80% RH non-condensing maximum
• Operating Altitude: 1000 meters above sea level maximum
• Storage Altitude: 1000 meters above sea level maximum

Connection & Network Features

• Fiber Support: Single-mode fiber optic compatibility
• Coaxial Support: Coaxial connector connectivity option
• Dual Media: Both fiber and coaxial connection support
• Signal Enhancement: Communication signal regeneration
• Network Extension: Extended communication range capability
• Signal Integrity: Maintained signal quality and strength

Compliance & Standards

• Regulatory Approval: CE marking for European compliance
• Safety Standards: Meets essential health and safety requirements
• Environmental Standards: Industrial environmental compliance
• Quality Certification: Manufacturer quality standards
• Industry Compliance: Relevant industrial communication standards
• System Compatibility: Modicon Quantum platform integration

Operating Environment Requirements

• Environment Type: Clean indoor industrial environments
• Chemical Protection: No corrosive chemicals in operating area
• Air Quality: Controlled atmosphere with minimal contaminants
• Installation Location: Protected areas within control cabinets
• Temperature Control: Maintained within specified range
• Humidity Control: Non-condensing conditions required

Installation Guidelines

• Install in Modicon Quantum series control racks or enclosures
• Connect single-mode fiber optic cables for optical connections
• Use appropriate coaxial cables for coaxial connectivity
• Maintain operating environment within 0-40°C temperature range
• Ensure installation area remains free from corrosive chemicals
• Verify all connections and signal transmission quality

Application & Network Integration

• Network Extension: Extends communication network range
• Signal Regeneration: Boosts and regenerates weak signals
• Media Conversion: Fiber and coaxial media support
• System Integration: Seamless Quantum platform integration
• Industrial Networks: Factory and process communication networks
• Reliability Enhancement: Improved network reliability

Packaging & Shipping Information

• Includes one Schneider Electric 140NRP95401 repeater module
• Package contains installation guide and technical documentation
• We ship via reliable carriers including FedEx, UPS, and DHL
• Industrial-grade packaging ensures component protection during transit
• Proper handling maintained throughout shipping process

Frequently Asked Questions

• What fiber type does it support? Single-mode optical fiber.
• Does it support coaxial connections? Yes, coaxial connector support included.
• Is it CE certified? Yes, CE marked for compliance.
• What temperature range? 0°C to 40°C operating temperature.
• What environment is required? Clean indoor environment without corrosive chemicals.
