Schneider Electric 140NWM05000 DIO Head-End Adaptor

Schneider Electric Modicon Quantum DIO Head-End Adaptor

The 140NWM05000 is a network head-end adaptor from Schneider Electric's Modicon Quantum series. This DIO module provides critical interface connectivity for industrial networks. It requires IP address configuration for proper network communication.

Core Technical Specifications

• Brand & Model: Schneider Electric 140NWM05000 (Modicon Quantum Series)
• Product Type: DIO head-end network adaptor module
• Network Requirement: IP address configuration required
• Physical Design: Removable door for easy access
• Bus Current: 900 milliamps total current requirement
• Power Dissipation: 4.5 Watts total power consumption
• Firmware Feature: Upgradable firmware for future enhancements

Communication Interfaces

• RS-232 Port: Serial communication interface support
• 100 Base-Fx: Fiber optic network connectivity
• 10/100 Base-T: Standard Ethernet connectivity
• Interface Variety: Multiple communication options
• Network Flexibility: Both copper and fiber support
• Serial Port Current: 750 mA dedicated serial port current

Electrical Specifications

• Total Current: 900 mA overall bus current requirement
• Serial Current: 750 mA serial port specific current
• Total Power: 4.5 Watts module power dissipation
• Serial Power: 3.8 Watts serial port power dissipation
• Fuse Protection: No internal fuse protection
• Power Management: Efficient power distribution

Environmental Specifications

• Operating Temperature: 0°C to 40°C reliable performance range
• Storage Temperature: 0°C to 50°C safe storage conditions
• Operating Humidity: Up to 80% RH non-condensing maximum
• Storage Humidity: Up to 80% RH non-condensing maximum
• Environmental Protection: Designed for controlled environments
• Installation Environment: Clean industrial settings

Features & Diagnostics

• Diagnostic LEDs: Visual status and fault indicators
• Removable Door: Easy access for maintenance
• Firmware Upgrade: Field-upgradable firmware capability
• Network Diagnostics: Communication status monitoring
• System Integration: Modicon Quantum platform compatibility
• Configuration Access: Easy setup and configuration

Installation Guidelines

• Install in Modicon Quantum series control racks or enclosures
• Configure unique IP address for network identification
• Connect appropriate cables to RS-232, fiber, or Ethernet ports
• Use removable door for convenient access during installation
• Maintain operating environment within 0-40°C temperature range
• Monitor diagnostic LEDs for system status information

Network Configuration

• IP Addressing: Required network address configuration
• Protocol Support: Industrial network protocols
• Interface Management: Multiple interface configuration
• Network Security: Standard industrial network security
• Data Communication: Reliable industrial data transfer
• System Monitoring: Network performance tracking

Packaging & Shipping Information

• Includes one Schneider Electric 140NWM05000 adaptor module
• Package contains installation guide and technical documentation
• We ship via reliable carriers including FedEx, UPS, and DHL
• Industrial-grade packaging ensures component protection during transit
• Proper handling maintained throughout shipping process

Frequently Asked Questions

• What interfaces does it have? RS-232, 100Base-Fx, and 10/100Base-T.
• Is an IP address required? Yes, IP configuration is mandatory.
• What is the removable door for? Easy access for maintenance.
• What power does it consume? 4.5W total, 3.8W serial port.
• What temperature range? 0°C to 40°C operating temperature.
