Schneider Electric 140NWM10000C Operator Panel

Schneider Electric 140NWM10000C Operator Panel

The 140NWM10000C is a robust operator interface panel designed for Schneider Electric's Modicon Quantum automation platform. This panel provides essential local monitoring and control capabilities with a clear LED display, enhancing user interaction with industrial control systems.

Technical Specifications

• Brand & Model: Schneider Electric 140NWM10000C
• Product Type: Operator Panel (HMI - Human Machine Interface)
• System Platform: Modicon Quantum Automation Series
• Display Type: LED-based display for clear status and data presentation
• Communication Ports: 2 connection ports
• Connector Types: MT-RJ and RJ-45 for network and programming connections
• Protection Rating: IP20 (protection against solid objects >12.5mm)
• Enclosure Rating: NEMA 1 for indoor use

Environmental Specifications

• Operating Temperature: 0 to 40 °C (32 to 104 °F)
• Operating Humidity: Up to 80% RH, non-condensing
• Storage Humidity: Up to 80% RH, non-condensing
• Operating Altitude: Up to 1000 meters (3280 feet) above sea level
• Designed for standard indoor industrial environments

Design & Compliance

• Standards: CE marked for compliance with European directives
• Enclosure: Designed for mounting on panels or enclosures
• Simple and durable interface suitable for plant floor operations

Communication & Integration

• Integrates directly with the Modicon Quantum PLC rack or via network connection
• The dual ports allow for connection to control networks and programming terminals
• Provides a local window into system status, alarms, and process variables
• Typical functions include display of setpoints, process values, and acknowledgment of faults

Typical Applications

• Local monitoring station for Quantum PLC-controlled processes
• Basic operator interface for machine control and status
• Industrial environments requiring a simple, reliable display without a full graphical HMI

Packaging & Shipping

• The 140NWM10000C operator panel ships as a complete unit.
• Includes the panel with its integrated display and connectors.
• Packaged securely to prevent damage during transit.
• Worldwide express shipping via FedEx, UPS, and DHL available.

Frequently Asked Questions (FAQ)

• What is an operator panel? It is a simple Human-Machine Interface (HMI) device that allows personnel to view system data and perform basic control functions locally.
• What type of display does it have? It uses an LED display, typically for showing numeric values, status codes, or simple messages.
• What are the MT-RJ and RJ-45 ports for? They are used for network communication (likely Modbus or Ethernet) and for connecting a programming/configuration tool.
• What does IP20 rating mean? It offers basic protection against touch by fingers and solid objects larger than 12.5mm, but it is not protected against water. It is for indoor use only.
• Can it be used outdoors? No, with its IP20 and NEMA 1 ratings, it is designed strictly for indoor environments protected from weather and dripping water.
• How is it programmed or configured? Configuration is typically done through the Quantum PLC programming software (Unity Pro) to define what data is displayed.
• What is the main advantage over a graphical HMI? It offers a cost-effective, reliable, and simple solution for applications where a full touchscreen graphical interface is not required.
