Schneider Electric 140XPP01000 Backplane Expander

Schneider Electric Modicon Quantum 140XPP01000 Backplane Expander

The 140XPP01000 is a Backplane Expander module for Schneider Electric's Modicon Quantum automation platform. This expansion unit enables additional I/O module capacity for growing control system requirements. It provides reliable electrical connectivity and mechanical support for extended Quantum configurations.

Product Identification

• Manufacturer: Schneider Electric
• Brand: Modicon
• Model Number: 140XPP01000
• Platform: Modicon Quantum automation system
• Product Type: Backplane expansion module
• Primary Function: System expansion and I/O capacity increase

Mechanical Specifications

• Slot Capacity: 10 module slots for additional I/O or specialty modules
• Construction Material: Aluminum alloy frame with steel mounting brackets
• Module Dimensions: 17.3 × 4.9 × 1.6 inches (440 × 125 × 40 mm)
• Weight: 3.5 lbs (1.6 kg) without installed modules
• Mounting Method: DIN rail or panel mounting options
• Module Pitch: Standard 0.8 inches (20.3 mm) per module slot
• Backplane Length: 8.0 inches (203 mm) of usable mounting space

Electrical Specifications

• Power Consumption: 5.2 Watts typical operational consumption
• Bus Voltage: 5 VDC ±5% from main backplane
• Bus Current Capacity: 2.5 Amps maximum per power rail
• Connection Method: 96-pin DIN 41612 connectors for module interface
• Contact Resistance: < 10 mΩ per contact pair
• Signal Integrity: Supports data rates up to 10 Mbps
• Grounding: Multiple grounding points with M4 grounding screws
• Isolation: 500 VAC between power rails and chassis

Expansion Capabilities

• Maximum Modules: Supports up to 10 additional modules of mixed types
• Module Compatibility: All Quantum 140 series I/O and communication modules
• Expansion Distance: Can be located up to 3.3 feet (1 meter) from main rack
• Cascade Capability: Supports daisy-chaining of multiple expanders
• Addressing Range: Automatic addressing for up to 31 modules per drop

Environmental Specifications

• Operating Temperature: 0 to 60°C (32 to 140°F)
• Storage Temperature: -40 to +85°C (-40 to +185°F)
• Relative Humidity: 5% to 95% non-condensing at 40°C
• Altitude Rating: Up to 2000 meters (6560 feet) without derating
• Vibration Resistance: 5-500 Hz, 2.0 G maximum acceleration
• Shock Resistance: 15 G for 11 ms duration
• Pollution Degree: Degree 2 per IEC 61131-2

Installation & Configuration

• Mounting Time: Approximately 15-20 minutes for typical installation
• Tool Requirements: Standard Phillips #2 screwdriver, 5 mm hex key
• Wiring Preparation: Pre-wired connectors reduce installation time by 60%
• Configuration: Automatic detection by Quantum CPU, no manual addressing required
• Cable Requirements: Requires expansion cable (e.g., 140XTS*****) for connection to main rack

Certifications & Standards

• Safety Standards: UL 508, CSA 22.2 No. 142
• EMC Compliance: IEC 61326-1, IEC 61000-6-2, IEC 61000-6-4
• Environmental Standards: RoHS compliant, REACH compliant
• Industrial Standards: IEC 61131-2, ISO 9001 manufacturing

Packaging & Shipping

• Package Contents: 140XBE10000 expander, mounting hardware, installation guide
• Package Weight: 4.2 lbs (1.9 kg) with packaging
• Package Dimensions: 19.7 × 6.3 × 2.4 inches (500 × 160 × 60 mm)
• Shipping: Available via FedEx, DHL, UPS with tracking
• Lead Time: Typically ships within 3-5 business days

Frequently Asked Questions

• How many expanders can be connected to one CPU? Typically up to 4 expanders per CPU, depending on configuration.
• Does it require external power? No, it receives power through the expansion cable from the main rack.
• Can different module types be mixed? Yes, the expander supports any combination of Quantum 140 series modules.

For system configuration assistance and compatibility verification for the 140XPP01000 Backplane Expander, contact our technical support.
