Schneider Electric 170ADO35000 Discrete Output Module

Schneider Electric 170ADO35000 Discrete Output Module

The Schneider Electric 170ADO35000 is a high-density discrete output module. It provides reliable switching for numerous DC loads in demanding industrial environments.

Technical Specifications

• Manufacturer & Model: Schneider Electric | 170ADO35000
• Product Series: Modicon Momentum
• Number of Outputs: 32 solid-state DC outputs
• Output Voltage: 0-24 V DC rated
• Continuous Current: 0.5 A per point
• Surge Current: 5 A for 1 ms
• Voltage Drop: < 0.5 V at 0.5 A
• Max Switching Frequency: 1 kHz
• Protection: Electronic overload protection
• Noise Immunity: 10 V/m (80-1000 MHz), 4/8 kV IEC 801-2
• Operating Temperature: 0°C to 60°C
• Certifications: CSA, UL, CE, RoHS
• Weight: 0.56 lbs (0.26 kg)

Installation & Wiring

• Mount the module on a standard 35mm DIN rail in a control panel.
• Connect your 24V DC field loads (e.g., solenoids, relays, indicators) to the 32 output terminals.
• Observe the maximum current rating of 0.5A per output point to ensure reliable operation.
• The module is designed for installation in Pollution Degree 2 environments.

Packaging & Shipping

• Includes one Schneider Electric 170ADO35000 output module.
• All necessary mounting hardware is provided.
• We ship orders worldwide via FedEx, UPS, and DHL.
• You will receive tracking information for your shipment.

Frequently Asked Questions (FAQ)

• How many outputs does it have? It provides 32 independent solid-state DC output channels.
• What is the output current rating? Each output can handle a continuous current of 0.5 Amps.
• Does it have overload protection? Yes, it features built-in electronic overload protection.
• What certifications does it hold? It is certified by CSA, UL, and complies with CE and RoHS directives.
• What is its noise immunity rating? It has high immunity to RF interference and electrostatic discharge (ESD).

Applications

• Controlling a large number of actuators, valves, and indicators in automated machinery.
• High-density output requirements in packaging, assembly, and material handling systems.
• Applications requiring robust performance in electrically noisy industrial environments.
• Distributed I/O control where space efficiency and high channel count are critical.
