Schneider Electric 170ENT11000 Industrial Ethernet Adapter

Schneider Electric 170ENT11000 Ethernet Network Adapter

The Schneider Electric 170ENT11000 is a high-performance Ethernet network adapter. It integrates Modicon Momentum I/O stations directly into standard TCP/IP networks for modern industrial communication.

Technical Specifications

• Manufacturer & Model: Schneider Electric | 170ENT11000
• Product Series: Modicon Momentum
• Network Protocol: Ethernet TCP/IP
• Data Speed: 10/100 Mbps auto-negotiation
• Communication Modes: Peer-to-peer and Master/Slave
• Network Topology: Star and Multidrop configurations
• Max Devices per Segment: Supports up to 32 units
• Max Cable Length: 1000 meters (with appropriate hardware)
• Physical Interface: RJ45 port (100BASE-TX)
• Addressing: Unique MAC address, user-configurable IP address
• Error Detection: CRC-32 verification for data integrity
• Safety Feature: Automatic fail-safe response
• Status Indicators: LEDs for Link/Speed, Activity, and System Status
• Weight: 0.25 lbs (0.11 kg)

Installation & Network Setup

• Mount the adapter module on a DIN rail within the control cabinet.
• Connect to the plant network using a standard Ethernet cable via the RJ45 port.
• Assign a unique IP address to the module for network identification.
• Configure the communication parameters using the appropriate configuration software.
• Observe the LED indicators to verify network link and operational status.

Packaging & Shipping

• Includes one Schneider Electric 170ENT11000 Ethernet network adapter.
• All required mounting hardware is provided.
• We ship orders globally via FedEx, UPS, and DHL.
• Tracking information is provided for every shipment.

Frequently Asked Questions (FAQ)

• What network speeds does it support? It supports both 10 Mbps and 100 Mbps Ethernet.
• How many devices can connect to it? A network segment can include up to 32 devices.
• What type of cable is required? It uses standard shielded twisted-pair (STP) Ethernet cable.
• How is it addressed on the network? It uses a configurable IP address for network communication.
• What do the LED indicators show? They show link speed, network activity, and overall module status.

Applications

• Connects Momentum I/O to supervisory SCADA systems and HMIs over Ethernet.
• Enables peer-to-peer data exchange between multiple PLCs and control devices.
• Integrates legacy Momentum systems into modern IIoT (Industrial Internet of Things) architectures.
• Ideal for factory-wide control networks and distributed process automation.
