Schneider Electric 170FNT11000 Fipio Communication Adapter

Schneider Electric 170FNT11000 Fipio Communication Adapter

The Schneider Electric 170FNT11000 is a dedicated Fipio network adapter. It enables high-speed, long-distance communication for Modicon Momentum I/O systems using fiber optic cabling.

Technical Specifications

• Manufacturer & Model: Schneider Electric | 170FNT11000
• Product Series: Modicon Momentum
• Network Protocol: Fipio
• Data Rate: 1 Mbps
• Transmission Medium: Optical Fiber (62.5/125 or 50/125)
• Max Devices per Segment: 31 (without repeater), 61 (with repeater)
• Max Cable Distance: 5 kilometers between devices
• Electrical Interface: Male Sub-D 9 connector
• Power Supply: From the Momentum I/O base unit
• Operating Temperature: 0°C to 60°C
• Certifications: UL, CE, CSA
• Weight: 0.19 lbs (0.09 kg)

Installation & Network Setup

• Install the adapter module on the Momentum base unit.
• Connect the fiber optic network cable to the adapter's optical port.
• Configure the network address and parameters for the Fipio network.
• The adapter draws power directly from the I/O base, requiring no separate power supply.
• Ensure the operating environment remains within the 0-60°C temperature range.

Packaging & Shipping

• Includes one Schneider Electric 170FNT11000 Fipio adapter module.
• All required mounting hardware is provided.
• We ship orders globally via FedEx, UPS, and DHL.
• Tracking information is provided for every shipment.

Frequently Asked Questions (FAQ)

• What is Fipio protocol? It is Schneider Electric's proprietary high-speed fieldbus protocol.
• What is the maximum network distance? Devices can be up to 5 km apart using fiber optic cable.
• How many devices can connect? A segment supports 31 devices, expandable to 61 with a repeater.
• What type of cable is used? It uses standard industrial multimode fiber optic cable.
• What are the key approvals? It is certified by UL, CSA, and carries the CE mark.

Applications

• Creating noise-immune, long-distance networks for Momentum I/O in large plants.
• Connecting remote I/O drops in harsh electrical environments where copper is unsuitable.
• Industrial networking in areas with high electromagnetic interference (EMI).
• Legacy system integration where Fipio is the established communication backbone.
