Schneider Electric 170PNT16020 Modbus Plus Adaptor

Schneider Electric 170PNT16020 Modbus Plus Adaptor

The Schneider Electric 170PNT16020 is a dedicated communication adaptor. It connects Modicon Momentum I/O stations to high-speed Modbus Plus industrial networks.

Technical Specifications

• Manufacturer & Model: Schneider Electric | 170PNT16020
• Product Series: Modicon Momentum
• Communication Protocol: Modbus Plus (MB+)
• Transmission Speed: 1 Mbit/s
• Network Access Methods: Token Bus and Peer-to-Peer
• Operating Temperature: 0°C to 40°C
• Storage Temperature: 0°C to 50°C
• Humidity Rating: Up to 80% RH (non-condensing)
• Maximum Altitude: 1000 meters for operation and storage
• Operating Environment: Clean indoor environments, free from corrosive substances
• Weight: 0.25 lbs (0.11 kg)

Installation & Network Setup

• Install the module on a DIN rail within your industrial control panel.
• Connect it to the Modbus Plus network trunk cable.
• Configure the module's network address and parameters.
• Ensure the operating environment stays within the specified temperature and humidity limits.

Packaging & Shipping

• Includes one Schneider Electric 170PNT16020 communication adaptor.
• All necessary mounting hardware is provided.
• We ship orders worldwide via FedEx, UPS, and DHL.
• You will receive a tracking number once your order ships.

Frequently Asked Questions (FAQ)

• What network protocol does it use? It uses the Modbus Plus (MB+) industrial protocol.
• What is the transmission speed? It operates at a fixed speed of 1 Megabit per second.
• What access methods are supported? It supports both token-passing and peer-to-peer communication.
• What is the operating temperature? It functions from 0°C to 40°C.
• Where should it be installed? It is designed for clean, indoor industrial settings only.

Applications

• Integrates Momentum remote I/O into Schneider Electric Modbus Plus networks.
• Ideal for building automation, factory control, and process monitoring systems.
• Enables high-speed data exchange between multiple PLCs and I/O devices.
• Used to create distributed control architectures in manufacturing facilities.
