Schneider Electric ABL8RPS24100 24V 10A Power Supply

Schneider Electric ABL8RPS24100 Universal Power Supply – Regulated 24V DC for Modicon Automation Systems

• Brand & Part Number: Schneider Electric ABL8RPS24100 – Modicon series regulated switch mode power supply.
• Input Voltage Range: Accepts 100…120V AC single phase or 200…500V AC phase-to-phase. Wide limits 85…132V AC and 170…550V AC.
• Output Specifications: Delivers 24V DC at 10A continuous. Power rating 240W. Adjustable output 24…28.8V DC.
• Efficiency & Power Factor: 87% efficiency rating. Power factor 0.68 at 240V AC, 0.69 at 120V AC.
• Inrush Current: 30A maximum during startup. Built-in harmonic filter meets IEC 61000-3-2.
• Power Dissipation: Only 31W at full load. Minimises cabinet heat buildup.
• Output Protection: Comprehensive safeguards against overload, overvoltage, short-circuit, undervoltage, and thermal events. Manual or automatic reset options.
• Mounting: Fits 35 x 7.5 mm and 35 x 15 mm symmetrical DIN rails. Requires vertical installation.
• Connections: Removable screw terminal blocks. Input accepts up to 4 mm², output up to 4 mm². Diagnostic relay included.
• Status Indication: Dual LED indicators for output voltage and output current. Green, red, and orange status codes.
• Operating Temperature: Functions from -25°C to +50°C without derating. Derated operation up to +60°C at 2000 m altitude.
• Protection Class: IP20 enclosure conforming to IEC 60529. Suitable for clean industrial environments.
• Safety Certifications: UL 508, CSA C22.2, EN/IEC 62368-1, IEC 60950-1, IEC 60204-1 SELV. Marked CE, CCC, EAC, KC, RCM.
• EMC Compliance: Meets IEC 61000-6-1, IEC 61000-6-3, EN 55024, IEC 61000-6-4, EN/IEC 61204-3.
• Physical Dimensions: Width 86 mm, height 125 mm, depth 145 mm. Net weight 1.0 kg.
• Dielectric Strength: 3500 V input-to-ground, 4000 V input-to-output, 500 V output-to-ground.
• Output Coupling: Supports parallel and series connection for increased power or voltage.

Frequently Asked Questions – ABL8RPS24100

• Is the ABL8RPS24100 brand new or refurbished?
  We supply only genuine, factory-sealed ABL8RPS24100 units. No used or refurbished stock.
• Do you have the ABL8RPS24100 in stock?
  Yes. We maintain real-time inventory. Same-day dispatch for orders placed before 15:00.
• What is the typical delivery time?
  We ship within 5 working days. Express shipping via FedEx, UPS, or DHL available.
• Can I use 220V AC input?
  Yes. The ABL8RPS24100 accepts 200…500V AC phase-to-phase. 220V AC falls within this range.
• What is the output adjustment range?
  Output voltage adjusts from 24V to 28.8V DC via internal potentiometer. Turn clockwise to increase.
• Does it support parallel operation?
  Yes. You can connect two ABL8RPS24100 units in parallel for redundancy or increased current. Use output decoupling diodes.
• What is the maximum ambient temperature?
  Full load up to 50°C. Derate linearly to 60% load at 60°C. No forced air required.
• Is this power supply SELV compliant?
  Yes. Certified SELV per IEC 60950-1, IEC 60204-1, and IEC 60364-4-41. Safe for direct connection to control circuits.
• What is your return policy?
  We accept returns within 30 days. Product must remain unopened in original packaging.
• Does it include a power factor correction filter?
  Yes. Built-in filter meets IEC 61000-3-2 Class A harmonic current limits.
