Schneider Electric ATV61HU40N4 Variable Speed Drive

Schneider Electric ATV61HU40N4 – Variable Speed Drive

The Schneider Electric ATV61HU40N4 is a robust variable frequency drive from the Altivar 61 series. Designed for demanding industrial environments, it provides precise and efficient control of three-phase asynchronous motors up to 4 kW (5 HP), featuring advanced functions for energy optimization and application-specific performance.

Core Electrical Specifications

• Part Number & Series: This is the Schneider Electric ATV61HU40N4 drive from the Altivar 61 range.
• Motor Power: Rated for 4 kW (5 HP) motor control.
• Input Supply: Three-phase 380-480V AC, compatible with both 50 Hz and 60 Hz supply frequencies.
• Line Current: Rated line current of 5.4 A.
• Apparent Power: 5.5 kVA.
• Overload Capacity: Handles a maximum transient current of 7.5 A for 60 seconds.
• Switching Frequency: Nominal switching frequency of 12 kHz, adjustable from 1 to 16 kHz for optimized motor performance and noise reduction.

Design & Protection Features

• Integrated EMC Filter: Built-in filter ensures compliance with electromagnetic compatibility standards and reduces electrical noise interference.
• Enclosure Protection: Rated IP20, providing basic protection against dust and contact with live parts, suitable for installation in control cabinets.
• Thermal Management: Designed with a heat sink for efficient heat dissipation, ensuring reliability and extended service life.
• Physical Specifications: Weight is approximately 11.34 kg (25 lbs), reflecting its robust construction.
• Product Identification: EAN code: 3389118080188.

Primary Industrial Applications

• Pump & Fan Control: Ideal for HVAC systems, water treatment plants, and industrial ventilation for significant energy savings.
• Conveyor & Material Handling: Provides smooth acceleration and deceleration for conveyor belts, lifts, and automated transfer systems.
• Machinery Drives: Controls speeds for mixers, crushers, extruders, and other processing equipment requiring variable torque.
• Energy Management: Used in applications where optimizing motor speed to match load requirements reduces overall power consumption.

Key Features & Benefits

• Precise Motor Control: Advanced algorithms ensure accurate speed and torque regulation for improved process control.
• Operational Flexibility: The wide adjustable switching frequency range allows tuning for specific motor characteristics and acoustic requirements.
• Built-in Protections: Offers comprehensive motor and drive protection features (overload, short-circuit, phase loss, etc.) as standard in the Altivar 61 series.
• Easy Integration: Standard industrial communication options (available via optional cards) and a user-friendly interface simplify integration into automation systems.
• Rugged Construction: Designed to withstand the electrical and environmental conditions of industrial settings.

Ordering & Support Information

• Compatibility: Part of the Altivar 61 ecosystem; compatible with standard three-phase asynchronous motors.
• Shipping: Product weight and size should be considered for logistics and panel mounting.
• Support: Configuration and parameterization are supported by Schneider Electric software tools like SoMove and detailed technical documentation.

The ATV61HU40N4 drive from Schneider Electric delivers reliable, efficient, and precise variable speed control for mid-power industrial motor applications, combining performance with robust protection.
