Schneider Electric Momentum 170ADM37010 Discrete Base

Introducing the Schneider Electric 170ADM37010 Discrete I/O Base

The 170ADM37010 is a high-density digital I/O module for Modicon Momentum. It provides sixteen discrete inputs and eight discrete outputs in one compact base. This module delivers reliable digital control for industrial automation systems.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric 170ADM37010
• Input Configuration: 16 discrete inputs organized in 4 groups
• Output Configuration: 8 discrete outputs organized in 2 groups
• Operating Voltage: 24 V DC for both inputs and outputs
• Maximum Voltage: Outputs support up to 30V DC operation
• Logic Type: Positive logic for consistent signal interpretation
• Output Technology: Solid-state switch outputs for reliable switching
• Protection: Features TC treatment for enhanced durability

Robust Design & Operating Environment

• Operating Temperature: Reliable performance from 0°C to 60°C
• Storage Temperature: Withstands -40°C to 85°C when not in use
• Humidity Tolerance: Operates at up to 95% relative humidity without condensation
• Physical Weight: Lightweight design at 1.00 lb (0.45 kg)
• Industrial Protection: Designed for standard industrial panel environments

Packaging & Shipping Information

• Package Includes: One (1) 170ADM37010 discrete I/O base module
• Shipping Methods: Global shipping via FedEx, UPS, and DHL
• Standard Packaging: Protective packaging ensures safe delivery

Installation & Integration Guide

• Mount this discrete I/O base onto your Modicon Momentum DIN rail
• Connect your 24V DC digital signals to the sixteen input channels
• Wire your output devices to the eight solid-state output channels
• The grouped organization simplifies wiring and maintenance tasks
• Ensure your power supply provides stable 24V DC within specifications
• This module is ideal for high-density digital I/O applications

Frequently Asked Questions (FAQ)

What types of devices can the 170ADM37010 control?

This module can control various 24V DC devices including relays, solenoid valves, pilot lights, and small contactors through its eight solid-state outputs.

How many input points does this module provide?

The 170ADM37010 provides sixteen discrete input points for monitoring switches, sensors, and other digital signals.

What is the advantage of solid-state outputs?

Solid-state outputs offer faster switching, longer life, and silent operation compared to mechanical relays. They have no moving parts to wear out.

Can this module handle higher voltage devices?

The outputs support up to 30V DC. For devices requiring higher voltages or AC power, you will need additional interface relays.

Is this suitable for high-speed counting applications?

While capable for general digital I/O, for high-speed counting consider specialized high-speed counter modules within the Momentum range.
