Schneider Electric NWBP85002 Modbus Plus Bridge

Schneider Electric NWBP85002 Modbus Plus Bridge – Reliable Communication for Modicon Platforms

• Brand & Part Number: Schneider Electric NWBP85002 – Modicon series communication bridge.
• Power Supply Range: Accepts 115…220 V AC or 24 V DC. No external converter required.
• Port Configuration: Four Modbus Plus ports enable multi-device integration and redundant paths.
• Protocol Support: Native Modbus Plus protocol ensures deterministic data exchange.
• Platform Compatibility: Works with both Modicon Premium and Quantum automation controllers.
• Mounting Options: Supports panel mounting and shelf mounting. Fits existing cabinet layouts.
• Physical Specification: Weight 1.81 kg (4.00 lbs). Compact footprint for dense environments.
• Environmental Tolerance: Rated for industrial automation networks. Resists electrical noise and vibration.
• Operating Temperature: 0…60 °C. Maintains signal integrity in factory conditions.
• Surge Immunity: Meets IEC standards for transient overvoltage protection.
• Isolation Voltage: 1500 V RMS between power and logic. Prevents ground loop interference.

Installation Guidelines for NWBP85002

• Mechanical Fixing: Use M4 screws for panel mounting. Torque to 1.2 Nm maximum.
• Power Connection: Connect AC or DC supply via removable terminal block. Wire gauge 0.5…2.5 mm².
• Port Wiring: Each Modbus Plus port accepts shielded twisted-pair cable. Keep total drop length below 450 m.
• Grounding: Attach protective earth directly to the chassis stud. Minimises EMI susceptibility.
• Space Clearance: Reserve 50 mm around ventilation slots. Ensures passive cooling efficiency.
• LED Indicators: Power, active, and fault LEDs simplify on-site diagnostics.

Frequently Asked Questions – NWBP85002

• Is the NWBP85002 brand new or refurbished?
  We supply only genuine, factory-sealed NWBP85002 units. No used or refurbished stock.
• Do you have the NWBP85002 in stock?
  Yes. We maintain real-time inventory. Same‑day dispatch for orders placed before 15:00.
• What is the typical delivery time?
  We ship within 5 working days. Express options available via FedEx, UPS, or DHL.
• Can I mount this bridge on a DIN rail?
  The NWBP85002 supports panel and shelf mounting only. Use an optional adapter plate for DIN rail.
• Does it work with Modicon Momentum?
  This model specifically supports Premium and Quantum. For Momentum, please check the NWBP85002 compatibility list.
• What is the maximum cable distance per port?
  Each Modbus Plus port supports 450 m total drop length at 1 Mbit/s.
• What is your return policy?
  We accept returns within 30 days. Product must be unopened and in original packaging.
