Schneider Electric TSXCANCA100 CANopen Cable

Schneider Twido TSXCANCA100 CANopen Standard Cable, 100m, IP20

The TSXCANCA100 from Schneider Electric is a 100-meter CANopen standard cable designed for industrial communication networks. This high-quality connecting cable provides reliable data transmission for Twido and other CANopen compatible systems. It features durable construction suitable for factory automation environments.

Technical Specifications

• Manufacturer & Brand: Schneider Electric / Twido
• Model Number: TSXCANCA100
• Product Type: Standard communication cable
• Bus Protocol: CANopen industrial network
• Accessory Type: Connecting cable for bus systems
• Primary Destination: CANopen bus network connections
• Cable Length: 328.08 feet (100 meters) total
• Certification Marking: CE compliant for European market
• Ingress Protection Rating: IP20 (protection against solid objects >12.5mm)
• Product Net Weight: 19.4 lb (8.8 kg)
• Flame Resistance: IEC 60332-1 compliant for flame propagation
• Cable Diameter: Approximately 8.0 mm (0.315 inches)
• Bend Radius: Minimum 50 mm (2 inches) for installation

Electrical Characteristics

• Conductor Type: Twisted pair with shield for noise immunity
• Conductor Size: 0.75 mm² (18 AWG) per conductor
• Number of Conductors: 4 conductors (2 twisted pairs)
• Shielding: Overall foil and braid shield with drain wire
• Characteristic Impedance: 120 Ω ±10% typical at 1 MHz
• Propagation Delay: 5 ns/m maximum (500 ns for 100m total)
• Capacitance: 60 pF/m maximum conductor to shield
• DC Resistance: < 25 Ω/km per conductor at 20°C
• Voltage Rating: 300V RMS maximum working voltage
• Temperature Rating: -20°C to +80°C (-4°F to +176°F) continuous

Mechanical & Physical Properties

• Cable Construction: Multi-conductor with color-coded insulation
• Insulation Material: PVC (Polyvinyl Chloride) for durability
• Jacket Material: PVC outer jacket in standard industrial gray
• Conductor Identification: Color-coded: CAN_H (white), CAN_L (blue), +24V (red), 0V (black)
• Shield Termination: Drain wire for proper grounding connection
• Tensile Strength: Minimum 50 N during installation
• Chemical Resistance: Resistant to oils, coolants, and industrial fluids

Packaging Information

• Unit Packaging (PCE): 1 piece per box
• Unit Dimensions: 8.661 × 13.780 × 13.780 inches (220 × 350 × 350 mm)
• Unit Gross Weight: 20.437 lb (9.270 kg)
• Master Carton (P12): 12 pieces per shipping carton
• Carton Dimensions: 39.37 × 31.496 × 47.244 inches (1000 × 800 × 1200 mm)
• Carton Gross Weight: 518.087 lb (235.000 kg)
• Reel Type: Standard industrial cable reel with protective ends

Installation Guidelines

• Network Topology: Suitable for linear bus topology up to 100 meters
• Termination Requirements: Requires 120 Ω termination resistors at both ends of bus
• Grounding: Shield must be grounded at one point only to prevent ground loops
• Cable Routing: Maintain minimum 200 mm (8 inches) separation from power cables
• Connection Method: Use proper CANopen connectors (e.g., 9-pin D-sub or terminal blocks)
• Pull Force: Maximum 50 N (11.2 lb) during cable installation
• Environmental Consideration: Indoor use only (IP20 rating)

Application & Compatibility

• Primary Systems: Schneider Electric Twido programmable controllers
• Network Compatibility: CANopen networks compliant with CiA 301/302 standards
• Baud Rates: Supports 10 kbit/s to 1 Mbit/s CANopen data rates
• Maximum Nodes: Supports up to 127 nodes on a single bus segment
• Typical Applications: Factory automation, material handling, packaging machinery
• System Integration: Connects PLCs, drives, I/O modules, and other CANopen devices

Standards & Certifications

• Flame Test Standard: IEC 60332-1 (flame propagation on single vertical insulated wire/cable)
• EMC Performance: Shielded design reduces electromagnetic interference
• RoHS Compliance: Compliant with Restriction of Hazardous Substances directive
• Quality Standards: Manufactured under ISO 9001 quality management system

Shipping & Handling

• Shipping Methods: Available via FedEx, UPS, DHL for global delivery
• Packaging Protection: Reel protected with end caps and plastic wrapping
• Lead Time: Typically ships within 3-7 business days
• Customs Documentation: Provided for international shipments as required
• Storage Recommendation: Store in dry, temperature-controlled environment

Frequently Asked Questions

• Can this cable be used outdoors? No, IP20 rating is for indoor use only.
• What connectors are needed? Standard 9-pin D-sub connectors or terminal blocks compatible with CANopen.
• Is the cable pre-terminated? No, it's supplied on a reel without connectors; termination is required during installation.

For network design assistance and compatibility verification for the TSXCANCA100 CANopen cable, contact our technical team.
