Schneider Modicon NW-BM85C002 | Network Bridge Multiplexer

Introducing the Schneider Electric NW-BM85C002 Multiplexer Module

The NW-BM85C002 is a communication multiplexer for Modicon Modbus Plus networks. This module manages data flow between devices on industrial networks. It provides reliable communication bridging and protocol handling for automation systems.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric NW-BM85C002
• Product Type: Industrial Multiplexer Module
• Communication Protocol: Standard Modbus Plus protocol
• Port Configuration: 8 data bits, 1 stop bit settings
• Port Priority: Configurable port priority for traffic management
• Physical Dimensions: 29 cm L x 21.5 cm W x 6 cm H
• Module Weight: Approximately 5.00 lbs (2.27 kg)
• Interface Support: Compatible with all Modbus Plus devices

System Integration & Installation

• Mounting Options: Flexible panel or rack mounting
• Power Compatibility: Designed for Modbus system power requirements
• Application: Network bridging and multiplexing functions
• Environment: Suitable for standard industrial automation networks
• Network Role: Serves as communication bridge between network segments

Packaging & Shipping Information

• Package Includes: One (1) NW-BM85C002 multiplexer module
• Shipping Methods: Worldwide shipping via FedEx, UPS, and DHL
• Standard Packaging: Protective packaging for industrial components

Installation & Configuration Guide

• Mount this module in your industrial panel or standard 19-inch rack
• Connect to your existing Modbus Plus network infrastructure
• Configure port priority settings based on your network traffic needs
• Use the 8 data bit, 1 stop bit configuration for standard communication
• This module bridges communication between different network segments
• Ensure proper power supply compatibility with your Modbus system

Frequently Asked Questions (FAQ)

What is the primary function of this multiplexer module?

The NW-BM85C002 manages and routes Modbus Plus communication between devices. It serves as a network bridge and traffic multiplexer for industrial automation systems.

What communication protocol does this module use?

This module operates exclusively on the Modbus Plus industrial communication protocol, a widely adopted standard in automation networks.

Can I configure port priorities on this device?

Yes, the module features configurable port priority settings. This allows you to manage network traffic flow based on your application requirements.

What are the mounting options for this module?

The NW-BM85C002 supports both panel mounting and standard 19-inch rack mounting for flexible installation in control cabinets.

How does this differ from the NW-BM85-000 model?

While both are multiplexers, the NW-BM85C002 is specifically designed for Modbus Plus networks, whereas the NW-BM85-000 offers RS-232 ports and broader protocol support.
