Schneider Momentum 171CCS76000 Processor Adapter Module

Product Overview

The 171CCS76000 is an M1/M1E Processor Adapter Module manufactured by Schneider Electric for the Modicon Momentum automation platform. This processor module provides reliable Modbus communication and substantial I/O capacity for industrial control applications.

Technical Specifications

• Manufacturer: Schneider Electric
• Part Number: 171CCS76000
• Product Type: M1/M1E Processor Adapter Module
• Product Line: Modicon Momentum Automation Platform
• GTIN: 3595861147812
• Processor Type: X86 Architecture (Intel/AMD)
• Clock Frequency: 32 MHz Operating Speed
• Flash Memory: 256 KB Program Storage
• RAM Memory: 256 KB Data Storage
• Word Length: 16-bit Data Processing
• Supply Voltage: 5.0 VDC ±5%
• Scan Time: 0.63 ms per Kilobyte
• Instruction Time: 1 ms per 1K Instructions
• Communication Protocol: Modbus Serial
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Operating Altitude: ≤ 2,000 m (6,562 ft)
• Net Weight: 0.042 kg (0.093 lb)
• Shipping Weight: 0.45 kg (1.00 lb)
• Country of Origin: France (FR)

Memory Configuration

• Total Flash Memory: 256 KB Non-Volatile Storage
• Program Memory (LL984): 12 KB Instruction Space
• Program Memory (IEC): 160 KB IEC Executive Space
• Data Memory: 4 KB Variable Storage
• Total RAM: 256 KB Volatile Memory
• Memory Optimization: Balanced Performance Design

I/O Capacity

• Discrete I/O: 2,048 Input / 2,048 Output Maximum
• Register I/O: 4,096 Words Total Capacity
• I/O Limit: 8,192 Bits Maximum Capacity
• I/O Words per Drop: 128 I/O (Concept), 80 I/O (ProWORX)
• System Expansion: Comprehensive I/O Support

Communication Ports

• Serial Port: RS-232C Non-Isolated Modbus Port
• I/O Bus Port: Momentum I/O Bus Connection
• Protocol Support: Modbus Serial Communication
• Connectivity: Dual-Port Industrial Architecture
• Interface: Standard Serial Communication

Software Compatibility

• Development Software: Concept V2.6 Programming
• Legacy Support: Modsoft ≥ V2.5 Compatibility
• Modern Environment: ProWORX NxT V2.0
• Windows Platform: ProWORX 32 Environment
• Programming Standards: LL984 and IEC Support

Physical Characteristics

• Material: Lexan Industrial-Grade Construction
• Protective Treatment: TC Coating Application
• Markings: CE Certification Compliance
• Design: Standard Momentum Module Format
• Weight: Lightweight at 0.093 lb Net Weight

Power & Electrical Specifications

• Voltage Requirement: 5.0 VDC with ±5% Tolerance
• Supply Method: Via Momentum I/O Base Connection
• Power Efficiency: Optimized Energy Consumption
• System Integration: Seamless Base Mounting

Environmental Specifications

• Relative Humidity: 5-96% (Non-Condensing)
• Shock Resistance: ≤15 gn Peak, 11 ms Half Sine
• Vibration Resistance: 1 gn / 0.75 mm d.a
• Industrial Enclosure: NEMA Type 250 Rated
• Environmental Class: Industrial Harsh Environment

Certifications & Standards

• Safety Certifications: UL and cUL Approved
• Hazardous Location: FM Class 1 Division 2
• Enclosure Standard: NEMA Type 250 Compliance
• Quality Assurance: Schneider Electric Standards

Package & Shipping

• Category: 18206-MOMENTUM PROCESSORS,I/O BASES,CONN.
• Discount Schedule: PC31
• Package Type: Single Unit Package
• Units per Package: 1 Processor Module
• Package Dimensions: 26 × 18 × 5.5 cm (10.2" × 7.09" × 2.2")
• Package Weight: 206 g (7.3 oz)
• Return Policy: Non-Returnable Item

Key Features

• 32 MHz X86 Processor for Reliable Control Performance
• 256 KB Flash and 256 KB RAM Memory Configuration
• RS-232C Modbus Serial Port for Industrial Communication
• 4,096 Register I/O Word Capacity for Control Applications
• Compatible with Concept, Modsoft, and ProWORX Software
• 5VDC Operation via Momentum I/O Base
• Multiple Certifications (UL, cUL, FM Class 1 Div 2)

Performance Specifications

• Processing Speed: 32 MHz for Industrial Control
• Execution Time: 1 ms per 1K Instructions
• Scan Efficiency: 0.63 ms per Kilobyte
• Response Time: Optimized for Real-Time Control
• Data Handling: 16-bit Word Processing

Frequently Asked Questions

What processor does this module use?
The 171CCS76000 features an X86-based processor (Intel/AMD) running at 32 MHz for industrial control applications.

What communication interface is provided?
This module includes one RS-232C non-isolated Modbus port for serial communication and one I/O bus port for Momentum system integration.

What memory capacity is available?
It provides 256 KB of flash memory and 256 KB of RAM, with specific allocations for LL984 (12 KB), IEC (160 KB), and data memory (4 KB).

What I/O capacity does it support?
The module supports up to 2,048 discrete I/O points and 4,096 register I/O words for control system expansion.

What software is compatible?
It supports Concept V2.6, Modsoft V2.5+, ProWORX NxT V2.0, and ProWORX 32 programming environments.
