Servo Motor MPL-A320P-MJ22AA | Allen-Bradley

Allen-Bradley MPL-A320P-MJ22AA Low-Inertia Servo Motor

Motor Core Specifications

Voltage Class 200 Volts AC

Rated Speed 5000 RPM

Peak Torque 18.6 Nm

Rated Torque 6.26 Nm

Frame Size 100 mm

Stack Length 2 inches

Rotor Inertia 0.98 x 10-4 kg-m²

Weight 7.3 kg

Feedback & Connection Details

Feedback Type Multi-turn high-resolution encoder

Connector Type Circular bayonet style

Shaft Type Keyed shaft for secure connection

Shaft Seal No shaft seal installed

Motor Brake No brake included

Environmental Ratings

Enclosure Rating IP50

Max Ambient Temperature 40°C

Storage Temperature -25°C to 85°C

Altitude Max 1000 meters

Vibration Resistance 5.9 m/s² max

Solve High-Speed Automation Challenges

Perfect for high-speed pick-and-place robots

Ideal for precise packaging and labeling machines

Enhances performance in CNC tool changers

Provides rapid response for conveyor indexing

Reduces cycle times in automated assembly

Key Advantages For Your Machine

Low inertia allows for extremely fast acceleration

High torque density in a compact frame saves space

Keyed shaft ensures a reliable mechanical connection

Smooth operation at high speeds reduces product wear

Maintains precise position control under varying loads

Package Includes

One MPL-A320P-MJ22AA Servo Motor

All new and original from factory

Global Shipping & Support

Shipped worldwide via FedEx UPS DHL

24/7 technical support available

Warranty Protection

Backed by a 12-month warranty
