Spare 4-Channel Relay Control Module 3500/32 149986-02

Bently Nevada Spare 4-Channel Relay Control Module 3500/32 149986-02

The 3500/32 Spare 4-Channel Relay Control Module is engineered to provide robust and reliable control in industrial applications. This module is vital for efficient monitoring and control of machines, enhancing operational safety.

Main Module Specifications

• Dimensions:
  • Height: 241 mm (9.50 in)
  • Width: 24.4 mm (0.96 in)
  • Depth: 242 mm (9.52 in)
• Weight: 0.7 kg (1.6 lb)

I/O Module Specifications

• Dimensions:
  • Height: 241 mm (9.50 in)
  • Width: 24.4 mm (0.96 in)
  • Depth: 99.1 mm (3.90 in)
• Weight: 0.4 kg (1.0 lb)

Environmental Conditions

• Operating Temperature: Ranges from -30°C to +65°C (-22°F to +150°F)
• Storage Temperature: Ranges from -40°C to +85°C (-40°F to +185°F)
• Humidity: Up to 95%, non-condensing

Electrical Specifications

The module supports a range of electrical parameters to ensure reliable performance:

• Minimum Switched Current: 100 mA @ 12 Vdc (Resistive load)
• Maximum Switched Current: 2 A @ 0V to 30 Vdc
• Maximum Switched Voltage: 30 Vdc
• AC Specifications:
  • Maximum Switched Voltage: 30 Vac
  • Maximum Switched Current: 2 A

Why Choose the 3500/32 Module?

The Bently Nevada 3500/32 module is essential for modern industrial systems, ensuring high performance and durability. With its compact design and comprehensive electrical specifications, it supports the demanding requirements of various applications, providing peace of mind and operational efficiency.
