Standard Transient Data Interface Module 3500/22M 138607-01

Bently Nevada 3500/22M TDI Module

• Manufacturer: Bently Nevada
• Product No: 3500/22M 138607-01

TDI Module Dimensions and Weight

The TDI Module is constructed with precision, featuring dimensions of 241.3 mm x 24.4 mm x 241.8 mm (9.50 in x 0.96 in x 9.52 in). Its weight is a mere 0.91 kg (2.0 lbs), ensuring easy installation and maintenance.

This module is ideal for various applications, combining compact design with robust functionality, ensuring reliability in most environments.

I/O Module Specifications

The I/O Module measures 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in), with a weight of 0.20 kg (0.44 lbs). This lightweight design facilitates easy integration into existing systems while maintaining high performance.

Performance and Environmental Specifications

The TDI Module features a wide operating temperature range from -30°C to +65°C (-22°F to +149°F) and a storage temperature range of -40°C to +85°C (-40°F to +185°F).

It is designed to operate effectively in environments with humidity levels of up to 95%, non-condensing, making it suitable for a variety of industrial applications.

Battery Life

The powered TDI Module boasts an impressive battery life of 38 years at 50°C (122°F), ensuring longevity and reliability for extended monitoring applications. In unpowered states, it can last 12 years at 50°C (122°F), providing flexibility for various operational needs.
