Introducing the Schneider Electric TSXMRPC001M SRAM Memory Module

The TSXMRPC001M is a configurable memory expansion module for TSX Micro PLC systems. This SRAM module increases program and data storage capacity for industrial controllers. It offers flexible memory configuration to match your specific application requirements.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric TSXMRPC001M
• Memory Type: High-speed SRAM technology
• Memory Capacity: Configurable from 192 kB to 1024 kB application memory
• Data Storage: Provides up to 832 kB of data storage capacity
• Installation Slot: Designed for installation in Slot 0 of compatible PLCs
• Environmental Compliance: Proactive RoHS directive compliance
• Module Weight: Lightweight at 0.168 lb (0.076 kg)
• Physical Dimensions: Compact 2.6 cm x 9.1 cm x 13.2 cm design

Robust Design & Operating Environment

• Operating Temperature: Reliable from 0°C to 60°C (32-140°F)
• Storage Temperature: Withstands -25°C to 70°C (-13 to 158°F)
• Humidity Range: Operates at 5-95% relative humidity without condensation
• Shock Resistance: Withstands 15 gn for 11 ms shock
• Vibration Resistance: Handles 1.5 mm peak-to-peak vibration (3-13 Hz)
• Package Weight: Shipping package weighs 3.03 oz (85.9 g)

Compatibility & Integration

• PLC Compatibility: Compatible with TSX57C, TSX570 to TSX576, TSXPCI572/3
• Platform Support: Designed for Modicon Premium Automation platform
• Product Type: Configurable SRAM application/file memory extension
• Application: Expands both program application memory and data storage
• Installation: Simple plug-in installation in designated processor slot

Packaging & Shipping Information

• Package Includes: One (1) TSXMRPC001M SRAM memory module
• Shipping Methods: International shipping via FedEx, UPS, and DHL
• Product Category: Separate parts for processor memory extension

Installation & Configuration Guide

• Install this memory module in Slot 0 of your compatible TSX Micro PLC
• Configure the memory allocation between application and data storage as needed
• Maximum configuration provides 1024 kB for applications and 832 kB for data
• This module is ideal for applications requiring extensive recipe storage or data logging
• The SRAM technology ensures fast access times for critical control applications
• Ensure the PLC is powered down during module installation to prevent damage
