TSXASY410 Output Module | Schneider Electric Premium PLC

Core Product Overview

• The Schneider Electric TSXASY410 is a precision analog output module.
• This module provides reliable control signals for industrial automation systems.
• It integrates seamlessly with the TSX Micro and Modicon Premium PLC platforms.

Key Technical Specifications

• Brand & Model: Schneider Electric TSXASY410
• Output Channels: 4 independent analog output channels
• Output Ranges: 0-20 mA, 4-20 mA, and ±10 V selectable
• Resolution: High 12-bit digital-to-analog conversion
• Accuracy: ±0.2% of full scale at 25°C
• Response Time: Fast 1 ms per channel
• Power Supply: 24 V DC operation with low 3 W consumption

Performance & Electrical Characteristics

• Conversion Time: 2.5 ms total update time
• Isolation: 1500 Vrms between channels and bus
• Load Impedance: <600 Ω for current, >1000 Ω for voltage
• Protection: Overload and short-circuit protection
• Connection: Screw terminal block for secure wiring
• Measurement Error: <1% across full temperature range

Environmental & Safety Ratings

• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -25°C to 70°C (-13°F to 158°F)
• Humidity Range: 10-95% non-condensing for operation
• Certifications: UL, CSA, CE, and marine certifications (GL, ABS, DNV)
• Protection Class: IP20 for basic environmental protection
• Pollution Degree: Level 2 for industrial environments

Installation & Wiring

• Mount the TSXASY410 module in your TSX PLC rack
• Connect 24 V DC power to the designated terminals
• Wire analog outputs to your field devices (actuators, valves, drives)
• Use appropriate cable shielding for noise-sensitive applications
• Configure output ranges via your PLC programming software

Packaging & Delivery

• One Schneider Electric TSXASY410 analog output module
• Includes installation guide and technical documentation
• Shipping via FedEx, UPS, or DHL express delivery
• Package dimensions: 10.2" x 7.09" x 2.2" (26x18x5.5 cm)
• Net weight: 0.77 lb (0.35 kg)

Frequently Asked Questions

How many output channels does this module have?

The TSXASY410 provides four independent analog output channels.

What output signals can it generate?

It outputs 0-20 mA, 4-20 mA current, or ±10 V voltage signals.

What is the resolution of the analog outputs?

The module offers high 12-bit resolution for precise control.

Is this module suitable for harsh environments?

Yes, it has industrial certifications and wide temperature operation.

What PLC systems is it compatible with?

It works with Schneider Electric TSX Micro and Modicon Premium PLCs.
