About the Product

Schneider Twido TSXCANCADD5 CANopen Cordset

The TSXCANCADD5 is a 5-meter CANopen cordset designed for medium-distance device connections in industrial networks.

Technical Specifications

  • Manufacturer: Schneider Electric / Twido
  • Model Number: TSXCANCADD5
  • Product Range: CANopen communication accessories
  • Bus Protocol: CANopen industrial fieldbus
  • Product Type: CANopen cordset assembly
  • Accessory Category: Connection accessories
  • Function: Connecting cable for device interconnection
  • Destination: CANopen bus network connections
  • Cable Length: 16.4 feet (5 meters)
  • Connector Type: 2 × female SUB-D 9-pin molded connectors
  • Certification: CE marked for European compliance
  • Ingress Protection: IP20 rating
  • Product Weight: 0.97 lb (0.44 kg)
  • Operating Temperature: -20°C to +80°C (-4°F to +176°F)

Electrical & Mechanical Properties

  • Conductor Size: 22 AWG (0.34 mm²) stranded copper
  • Cable Construction: Twisted pair with overall foil/braid shield
  • Shield Termination: Connected to connector shells at both ends
  • Contact Plating: Gold over nickel plating
  • Pin Configuration: Standard CANopen pinout
  • Dielectric Strength: 500V AC for 60 seconds
  • Cable Diameter: Approximately 6.2 mm (0.244 inches)
  • Bend Radius: Minimum 50 mm (2 inches)
  • Maximum Voltage: 30V DC continuous

Package Information

  • Unit Package (1 PCE): Single cordset unit
  • Package Dimensions: 0.8 × 8.3 × 10.6 inches (20 × 211 × 269 mm)
  • Package Weight: 15.8 oz (449 grams)
  • Bulk Package (10 S02): 10 units per shipping carton
  • Carton Dimensions: 5.9 × 11.8 × 15.7 inches (150 × 300 × 399 mm)
  • Carton Weight: 9.90 lb (4.49 kg)

Installation & Application

  • Connection Purpose: Medium-distance device connections
  • Network Topology: Point-to-point in CANopen networks
  • Tool Requirements: No special tools needed
  • Installation Time: < 1 minute per connection
  • Compatibility: Standard CANopen devices with 9-pin D-sub male ports

Shipping & Support

  • Shipping Methods: Available via FedEx, UPS, DHL
  • Lead Time: Typically ships within 2-4 business days
  • Technical Support: Available for installation questions

For compatibility and technical support for the TSXCANCADD5 cordset, contact our team.
