TSXH5724M Hot Standby Processor | Schneider Electric

Core Product Overview

• The Schneider Electric TSXH5724M is a high-performance micro PLC processor.
• This Unity Hot Standby processor delivers reliable control for complex automation.
• It serves as the central brain for the Modicon Premium and TSX Micro platform.

Key Technical Specifications

• Brand & Model: Schneider Electric TSXH5724M
• I/O Capacity: 1024 discrete I/O and 80 analog I/O points
• Communication Ports: Ethernet TCP/IP, USB, and RS485 serial link
• Memory: 768 kB program memory with PCMCIA card (192 kB without)
• Processing Speed: 0.039-0.073 µs per instruction for fast execution
• Rack Configuration: Supports 1 rack with 6, 8, or 12 slots
• System Overhead: Low 1 ms cycle time for the master task

Performance & Communication Features

• Instruction Speed: Up to 15.75K instructions per ms for Boolean logic
• Ethernet Port: 10BASE-T/100BASE-TX for network connectivity
• USB Port: Type A port with 12 Mbit/s for programming
• Serial Port: RS485 link at 19.2 kbit/s for legacy devices
• Process Control: Manages up to 10 channels (30 simple loops)
• Application Channels: 24 channels for specialized functions

Memory & Expansion Options

• Internal RAM: 192 kB data memory expandable via PCMCIA
• PCMCIA Support: Adds 16 MB additional data storage capacity
• Object Areas: 192 kB data exchange via CPU Sync link
• Data Words: 32464 internal words and 32760 constant words
• Application Structure: Single master task architecture
• Programming Software: Designed for use with Unity Pro

Environmental & Safety Ratings

• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -25°C to 70°C (-13°F to 158°F)
• Certifications: CE, UL, CSA, and marine certifications (ABS, DNV, GL)
• Protection Class: IP20 rating for basic environmental protection
• LED Indicators: Multiple status lights for Ethernet, run, error, and activity
• Current Consumption: 1880 mA at 5 V DC from the backplane

Installation & Integration

• Install the TSXH5724M processor in slot 0 of your TSX rack
• Connect Ethernet cable for network communication and programming
• Use USB port for direct connection to programming workstation
• Configure I/O modules in the remaining rack slots (up to 12 total)
• Program and monitor using Schneider Electric Unity Pro software

Packaging & Delivery

• One Schneider Electric TSXH5724M Unity Hot Standby processor
• Includes comprehensive user manual and documentation
• Shipping via FedEx, UPS, or DHL express international service
• Package dimensions: 10.2" x 7.09" x 3.7" (26x18x9.5 cm)
• Net weight: 1.23 lb (0.56 kg)

Frequently Asked Questions

What is the maximum I/O capacity of this processor?

The TSXH5724M supports up to 1024 discrete I/O and 80 analog I/O points.

What communication ports are included?

It includes Ethernet TCP/IP, a USB port, and an RS485 serial link.

Can memory be expanded?

Yes, using a PCMCIA card to add up to 16 MB of additional storage.

What software is used to program this PLC?

It is programmed using Schneider Electric's Unity Pro software.

How many rack slots does it support?

It controls one rack that can hold 6, 8, or 12 I/O modules.
