XNX-AMAE-NNNNN Honeywell Explosion-Proof Transmitter ATEX

Honeywell XNX-AMAE-NNNNN Explosion-Proof Universal Transmitter

• Brand & Model: Honeywell XNX-AMAE-NNNNN (Explosion-Proof XNX Universal Transmitter).
• Approval: A = ATEX/IEC certified for Zone 1/2 hazardous locations.
• Entry Type: M = M25 metric cable entry.
• Material: A = Aluminium housing (lightweight, robust).
• Personality: E = Interface for Electrochemical Cartridges (includes IS Barrier and Adaptor) – for XNX Toxic and Oxygen Sensors.
• Option: N = No option installed.
• Local HART: N = No option installed.
• Sensor & Range: NNN = None (sensor ordered separately).
• Weight: 2.8 kg (unit only).

Technical Specifications

• Measurement Range: Depends on connected electrochemical sensor (toxic or oxygen).
• Frequency Response: Optimised for electrochemical cell signal conditioning.
• Sensitivity: Factory-calibrated for high accuracy with XNX sensors.
• Linearity: Exceptional linearity across the full sensor range.
• Resolution: 16-bit ADC for precise gas concentration readings.
• Temperature Range: -20°C to +55°C (ambient).
• Environmental Protection: IP66/IP67 rated against dust and water ingress.
• Immunity: Built-in EMI/RFI shielding for stable measurements.
• Explosion-Proof Rating: ATEX/IEC Ex d IIC T6 Gb.
• Weight: 2.8 kg.

Installation Guidelines

• Mount the XNX-AMAE-NNNNN on a rigid, vibration-free surface.
• Use the M25 cable gland (provided) for wiring entry.
• Connect the electrochemical cartridge to the IS barrier adaptor.
• Configure the personality (E) via the internal DIP switches.
• Ensure proper earth grounding for explosion-proof compliance.
• Apply 24V DC power and perform a sensor calibration routine.

Package Contents

• 1 x Honeywell XNX-AMAE-NNNNN transmitter unit.
• 1 x M25 cable gland (pre-fitted).
• 1 x mounting bracket with fixing screws.
• 1 x wiring diagram and quick-start guide.
• 1 x documentation CD (manual and certificates).

Shipping & Logistics

• We ship via FedEx, UPS, or DHL (global express delivery).
• Dispatch within 5 working days from order confirmation.
• All units are brand new and original Honeywell products.
• Stock available – ready for immediate shipment.

Frequently Asked Questions (FAQ)

• Q: Is the XNX-AMAE-NNNNN suitable for Zone 1 hazardous areas?
  A: Yes, it carries ATEX/IEC Ex d IIC T6 Gb certification.
• Q: What sensors does this transmitter support?
  A: It works with XNX toxic and oxygen sensors using the electrochemical cartridge interface.
• Q: Do you have this model in stock?
  A: Yes, we maintain inventory for fast dispatch.
• Q: What is the housing material and weight?
  A: The aluminium enclosure weighs 2.8 kg.
• Q: What is the return policy?
  A: We accept returns within 30 days of delivery.
• Q: Which courier do you use?
  A: We choose FedEx, UPS, or DHL for reliable tracked shipping.
