Technical Specifications for 1756-OB16E Basic Information Manufacturer: Rockwell Automation Brand: Allen-Bradley Part Number: 1756-OB16E Module Type: Digital DC Output Module Series: ControlLogix Output Specifications No. of Outputs: Sixteen (16) Output Voltage Range: 10-31.2 VDC Nominal Output Voltage: 24VDC Maximum Output Current Rating (Point): 1...

Technical Specifications for 1756-OB16I Basic Information Brand: Allen-Bradley Part Number: 1756-OB16I Module Type: Isolated DC Output Module Outputs: 16-Point Individually Isolated Electrical Specifications Voltage: 12-24 Volts DC Sink-Source Operating Voltage Range: 10-30 Volts DC Output Delay Time (OFF to ON): 1 ms max Output...

Allen-Bradley 1756-OB16IEF ControlLogix Fast Isolated Output Module – 16 Points, 10-30V DC Product Overview The Allen-Bradley 1756-OB16IEF is a high-speed, isolated DC output module featuring ultra-fast 25μs response time and 16 individually isolated outputs. Designed for precision control applications, it supports Pulse Width Modulation...

Allen-Bradley 1756-OB16IEFK ControlLogix Isolated DC Output Module Core Features The 1756-OB16IEFK delivers 16 isolated DC outputs with 2A switching capacity per point. This industrial-grade module operates across a 10-30V DC range and features point-level electronic protection for reliable operation in demanding environments. Technical Specifications...

Allen-Bradley 1756-OB16IS Scheduled Isolated Output Module Key Features 16 isolated DC outputs (10-30V) 8 synchronized scheduled outputs 1ms ON / 2ms OFF switching speed CIPSync architecture compatible Individual channel isolation Technical Specifications Output type: Sinking/Sourcing DC Current rating: 2A @ 30°C (1A @ 60°C)...

1756-OB32 Technical Specifications 🔧 Manufacturer: Rockwell Automation 🏭 Brand: Allen-Bradley Outputs: 32-Point 📈 Module Type: DC Output Module Voltage: 12-24 Volts DC Source Operating Voltage Range: 10-31.2 Volts DC Output Delay Time, OFF to ON: 60 µs nom/1 ms max Current Draw @ 5.1V:...

Allen-Bradley 1756-OB8 ControlLogix 8-Channel Digital Output Module Core Features 8-channel 24VDC digital output High-speed switching (1ms ON / 2ms OFF) Removable terminal blocks (RTB) for easy wiring Compatible with all ControlLogix chassis Technical Specifications Output type: Sourcing (10-30VDC range) Current rating: 2A per point...

Allen-Bradley 1756-OB8I ControlLogix 8-Point Isolated DC Output Module Key Specifications • 8 individually isolated outputs • 12-24VDC nominal (10-30V range) • 2A current per point @ 60°C • 16A total module current • 0.5V max voltage drop @ 2A • 4A surge current (10ms...

1756-OBV8S ControlLogix 8-Channel Safety Output Module Safety-Critical Performance 8 dedicated safety outputs (10-30VDC) 0.5A per channel current rating Certified for safety applications Short-circuit and overcurrent protection Fast response time for emergency systems Technical Specifications Voltage Range: 10-30VDC Current per Point: 0.5A max Total Current:...

Technical Specifications for 1756-OF4 Product Information Brand: Allen-Bradley Part Number/Catalog No: 1756-OF4 Series: ControlLogix Module Type: Analog Output Module Outputs Specifications Outputs: 4 Current-Voltage Output Voltage Range: ±10V Output Current Range: 4…20 mA Voltage Resolution: 15 bits across 10.5V, 320 µV/bit Current Resolution: 15...

Technical Specifications Manufacturer: Rockwell Automation Brand: Allen-Bradley Part Number: 1756-OF6CI Series: ControlLogix Module Type: Isolated Analog Output Module (Current Loop) Output Points: 6 Isolated Channels Current Range: 0…21 mA Resolution: 13 bits (2.7 µA increments) Backplane Current Requirements: 250 mA at 5V DC, 300...

Allen-Bradley 1756-OF6VI Analog Output Module - Precision Voltage Control MODULE HIGHLIGHTS 6-channel isolated voltage output ±10VDC output range per channel 14-bit high resolution (1.3mV) 0.5% full-scale accuracy IEEE 32-bit floating point data PERFORMANCE DATA Conversion speed: <2ms settling time Output impedance: 1 Ohm Load...

Allen-Bradley 1756-OF8I Analog Output Module Key Features • 8 isolated output channels • Voltage and current output capability • 16-bit high resolution • Individual channel configuration Output Specifications Voltage Ranges: -10 to +10V, 0-10V, 0-5V Current Ranges: 0-20mA, 4-20mA Resolution: 16-bit (0.32μA/count) Accuracy: ±0.05%...

1756-OF8IH ControlLogix Isolated HART Analog Output Module Key Features 8 fully isolated differential outputs Integrated HART modem per channel (HART 5/6/7) 15-bit resolution (0-20mA/4-20mA) ±24VDC overvoltage protection Channel-to-channel isolation Technical Specifications Output Range: 0-20mA / 4-20mA Resolution: 15-bit Isolation: 250V outputs-to-backplane (3535V tested) Accuracy:...

Allen-Bradley 1756-OG16 Digital DC Output Module Core Features • 16-Point TTL Outputs: 5V DC logic control • High-Speed Switching: 450μs (OFF→ON) / 700μs (ON→OFF) • Robust Load Capacity: 24mA per point (384mA total) • Wide Voltage Range: 4.5V–5.5V DC operation • Low Power Consumption:...

Allen-Bradley 1756-OH8I Isolated DC Output Module Key Features • 8 Isolated Outputs: 120V DC sink/source • High Current Capacity: 2A per point (8A total) • Wide Voltage Range: 90-146V DC operation • Fast Switching: 2ms response time • Robust Isolation: 250V output-to-backplane • Industrial...

Allen-Bradley 1756-ON8 AC Output Module Module Highlights • 8-point AC output module for industrial control • 240V AC rating (10-30V AC operating range) • 2A per point output capacity (4A total @60°C) • Compact design fits standard ControlLogix chassis • LED status indicators for...

Technical Specifications for 1756-OW16I Basic Information Manufacturer: Rockwell Automation Brand: Allen-Bradley Part Number: 1756-OW16I Module Type: Digital DC Sourcing Output Series: ControlLogix Output Specifications No. of Outputs: Sixteen (16), individually isolated channels Operating Voltage Range: 5…125V DC; 10…240V AC Electrical Characteristics Current Draw @...

Allen-Bradley 1756-RIO ControlLogix Remote I/O Module Core Specifications Network Role: Scanner or Adapter Max Racks: 32 physical racks (0-76 addressing) Data Types: Digital/Analog/Block Transfer Isolation: 50V continuous (RIO to backplane) Power Draw: 450mA @5.1V DC, 5mA @24V DC Thermal Dissipation: 8.5 BTU/hr Industrial Applications...

Allen-Bradley 1762-IA8 Digital Input Module Weight: 0.2 kg Input Power: 120 Volts AC Voltage Category: 100 to 120 Volts AC Number of Inputs: 8 Input Isolation Voltage: 500V AC Operating Temperature: -20°C to 55°C (-4°F to 131°F) Signal Types Supported: AC/DC compatible Highlighted Features...
