1769-PB4 | CompactLogix DC Power Supply

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (14 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Fornecedor:

    Allen-Bradley

  • Tipo:

    Power Supply

  • Tags Power supply

Sobre o Produto

Allen-Bradley 1769-PB4 CompactLogix DC Power Supply

Key Specifications

  • Input Voltage: 19.2-31.2V DC (24V DC nominal)
  • Output Current: 4.0A @ 5V DC | 2.0A @ 24V DC
  • Power Capacity: Supports up to 16 I/O modules (8 per side)
  • Efficiency: 100VA @ 24V DC input
  • Protection: 30A inrush current protection

Technical Details

Power Dissipation: 14.5W @ 60°C (140°F)
Isolation Voltage: 75V continuous (tested at 1697V DC)
Fuse Type: Wickmann 19193-6.3A or Littelfuse 021706.3MXP
Dimensions: 118 x 70 x 87mm (4.65 x 2.76 x 3.43in)
Weight: 1.39 lbs (630g)

Installation Requirements

  • 14 AWG (2.5mm²) copper wire minimum
  • 50mm clearance recommended for ventilation
  • DIN rail or panel mount options
  • Protective enclosure required
  • IEC Class 1 grounding mandatory

System Compatibility

  • CompactLogix 5370 controllers
  • 1769 I/O modules
  • MicroLogix 1500 systems
  • Studio 5000 programming environment

Shipping Information

  • UPC: 10612598276896
  • Shipping weight: 2 lbs (0.9kg)
  • Dimensions: 8 x 8 x 5 inches
  • Certifications: c-UL-us, CE, C-Tick
