IS200ERBPG1A Exciter Regulator Backplane ERBP

GE IS200ERBPG1A Exciter Regulator Backplane Module

Backplane Architecture

• Central Connectivity Hub: Interconnects all mounted printed circuit boards
• Communication Pathways: Establishes vital data exchange routes between modules
• Board Identification System: Integrated serial bus for standardized interface
• Configuration Flexibility: Master selection jumpers for simplex/redundant modes
• Power Distribution: Centralized power management for all connected boards

Supported Board Modules

• ACLA: Application Control Layer board
• DSPX: Digital Signal Processing board
• ERIO: Exciter Regulator Input/Output board
• EPSM: Exciter Power Supply Module
• ERDD: IGBT Exciter Regulator Interface and Dynamic Discharge board
• EROC: Exciter Regulator Options Card

Power Distribution System

• Main Power Inputs: TB1 (Positive) and TB2 (Negative)
• Fan Power Outputs: J1F1 and J1F2 connectors for system cooling
• External Board Power: Front panel connectors for additional components
• Module Power Supply: J5M1 for ERRR board, J16 for EDCF board
• Redundant System Power: J3 for ERRB backplane connectivity

Connector Configuration

• Keypad Interface: J4 connector for user input
• Backplane Connectors: 3U/6U VME 96-pin or 128-pin DIN standards
• Top Panel Layout: Five connectors including keypad and plug interfaces
• Communication Protocols: Ethernet Modbus and serial communication support
• Integration Capability: Stand-alone retrofitted application connectivity

System Identification Features

• Board ID Device: Programmed with barcode serial number and hardware data
• Slot Recognition: Enables seamless interaction with associated controls
• Hardware Tracking: Board type and revision information storage
• Standardized Interface: Uniform identification across all installed boards

Physical Specifications

• Weight:1.45kg
• Manufacturing Origin: United States
• Series Compatibility: EX2100 and Mark VI systems
• Availability Status: Currently in stock

Operational Modes

• Simplex Configuration: Single system operation mode
• Redundant Setup: Dual system for backup operation
• Mode Selection: Configurable through master selection jumpers
• Application Flexibility: Adaptable to various exciter regulator requirements

Integration Capabilities

• EX2100 System Compatibility: Designed for excitation control systems
• Retrofit Applications: Support for stand-alone system upgrades
• Protocol Support: Built-in Ethernet Modbus and serial communication
• Modular Expansion: Accommodates multiple board types simultaneously

Cooling System Support

• Dual Fan Power: Dedicated connectors for J1F1 and J1F2
• Thermal Management: Integrated cooling system power distribution
• System Reliability: Enhanced thermal control for stable operation

Package Contents

• IS200ERBPG1A Backplane Module
• Installation documentation
• Integration guidelines
• Technical specifications

Service & Support

• 12-Month Warranty: Comprehensive manufacturer coverage
• Technical assistance available
• Integration support services
• Quality certification
