Meggitt Vibro-Meter 913-402-000-012/A2-E090-F0-G000

Meggitt 913-402-000-012/A2-E090-F0-G000 Explosion-Proof Proximity Sensor

The Meggitt 913-402-000-012/A2-E090-F0-G000 is an intrinsically safe proximity measurement system designed for hazardous environments. This explosion-proof sensor provides reliable non-contact vibration monitoring with extended cable reach.

Technical Specifications

• Complete Model: 913-402-000-012/A2-E090-F0-G000
• Safety Certification: Ex i Intrinsic Safety for Explosive Environments
• Measurement Range: 2 mm or 4 mm options
• Frequency Response: DC to 20 kHz (-3 dB)
• Cable Length: 9.0 meter extension (±900 mm)

Safety & Environmental Ratings

• Explosion-Proof Certification: Ex i Intrinsic Safety Standard
• IP68 Protection: Fully protected transducer tip and cable
• Wide Temperature Range: -40°C to +180°C operating temperature
• Hazardous Area Rating: -40°C to +195°C in Ex Zones
• Robust Construction: Vibration 5g, Shock 15g resistance

Physical Construction

• Stainless Steel Housing: AISI 316L material
• Sensing Element: 8mm wire coil with Torlon tip
• Cable Type: FEP covered 70Ω coaxial, 3.6mm diameter
• Connectors: Self-locking miniature coaxial type
• Weight: 0.22 kg compact design
• Installation: Two M4 screw mounting

Electrical Requirements

• Power Source: Requires IQS900 signal conditioner
• Connection: Hand-tighten connectors until locked
• Cable Protection: Standard version without additional hose
• Chemical Resistance: FEP coating provides excellent protection

Performance Characteristics

• Temperature Drift: Less than 5% in operating range
• Short-Term Survival: Up to +220°C maximum
• Cable & Connector Rating: -40°C to +200°C
• Environmental Sealing: IP68 for harsh conditions

Applications

• Hazardous area vibration monitoring
• Explosive environment machinery protection
• Shaft relative vibration measurement
• Condition monitoring in Ex zones
• API 670 compliant installations

Frequently Asked Questions

• What does Ex i certification mean? Intrinsic Safety certification for use in potentially explosive atmospheres.
• What is the maximum cable length? This model includes a 9.0-meter cable with ±900 mm tolerance.
• Is additional hose protection available? This standard version operates without flexible hose protection.
• What temperature can it withstand? Operates from -40°C to +180°C with short-term survival to +220°C.
