Allen-Bradley 2711P-B15C10D2 PanelView Plus 7 HMI

Allen-Bradley 2711P-B15C10D2 PanelView Plus 7 Technical Specifications

Product Overview

• The Allen-Bradley 2711P-B15C10D2 delivers superior industrial interface performance. This PanelView Plus 7 model combines a large 15-inch display with robust communication capabilities. It provides reliable operation in demanding factory environments.

Display Features

• 15-inch High-Brightness Color Display with 300 nits intensity
• Analog Resistive Touchscreen for precise input control
• Integrated Keypad Input for flexible operation methods
• 50,000-Hour Backlight Life for reduced maintenance costs

Hardware Specifications

• Memory Capacity: 128MB onboard memory for application storage
• Communication Protocol: DeviceNet network connectivity
• Expansion Capability: SC card slot for additional memory
• Power Supply: 18-32VDC industrial power operation
• Battery Backup: 4-year battery for data retention

Industrial Performance

• Rugged construction withstands harsh industrial environments
• High-visibility display ensures clear viewing in bright conditions
• Dual input options provide operational flexibility
• Network connectivity enables seamless system integration

Physical Specifications

• Part Number: 2711P-B15C10D2
• Product Series: PanelView Plus 7 Industrial HMI
• Shipping Weight: 15 pounds (6.8 kilograms)
• Unit Dimensions: 19.2 × 14.4 × 3.2 inches

Industrial Applications

• Factory automation control systems and monitoring
• Process control applications in manufacturing
• Packaging machinery operation interfaces
• Material handling equipment control panels

Integration Benefits

• The Allen-Bradley 2711P-B15C10D2 offers easy integration into existing systems. Its DeviceNet protocol ensures compatibility with Allen-Bradley controllers. The large display provides excellent visibility for operators.
